Page 652 - Deko-Light Light Impressions 2019-20
P. 652
FLEXIBLE LED-STRIPE
Dim. L x W x H: 3000 x 10 x 3 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 4 cables [3x V-, V+]
840249 450 - 630 nm 180 LEDs 28 W 1150 lm / Stripe 383 lm / Meter EEI: A
12 SMD 120° 3 CH IP20 - 15°C M M
5050 + 50°C
Cutting option
over to 50 mm / 3 LED
FLEXIBLE LED-STRIPE
Dim. L x W x H: 5000 x 10 x 3 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 4 cables [3x V-, V+]
840250 450 - 630 nm 300 LEDs 40 W 1400 lm / Stripe 280 lm / Meter EEI: A
12 SMD 120° 3 CH IP20 - 15°C M M
5050 + 50°C
Cutting option
over to 50 mm / 3 LED
LED-STRIPES | 3 Channel 651
