ELECTRICAL

POWER TRIM EXTENSION HARNESSES POWER TRIM EXTENSION HARNESS

Plugs into remote control or trim panel with 3 blade connectors.

POWER TRIM EXTENSION HARNESS

84-865772T02
24 ft.(4.88 m) harness.
This harness connects the remote control 4 pin Molex connector to the newer
design 3 pin Packard pump trim pump connector.
MCM/MIE
46838A 4
10 ft.(3.05 m) harness and 3 blade connectors. POWER TRIM EXTENSION HOSE/HARNESS KIT
Fits Mercury/Mariner and MCM models with power trim.
46838A 6 POWER TRIM EXTENSION HOSE/HARNESS KIT
20 ft.(6.1 m) harness and 3 blade connectors. Note: Use with dual solenoid trim
pump only.
ELECTRICAL POWER TRIM EXTENSION HARNESS
Fits Mercury/Mariner and MCM models with power trim.

32-865384A01
Includes a 6 ft (1.8M) harness and 4 ft (1.2M) hoses
Fits 1983 and newer MCM models

84-817659T01 POWER TRIM ADAPTOR HARNESSES
16 ft.(4.88 m) harness.
This harness connects the remote control 4 pin Molex connector to the traditional 3 POWER TRIM ADAPTER HARNESS
blade Mercury pump trim pump connector.
MCM/MIE
84-881125A 1
24 ft.(4.88 m) harness.
This harness connects the remote control 4 pin Molex connector to the traditional 3
blade Mercury pump trim pump connector.
MCM/MIE
POWER TRIM EXTENSION HARNESS

84-865770A02
12 in.(305 mm) harness.
To convert older P/T pump with 3 blade connector to newer remote control harness
with 3 pin Packard connector.

84-865772T01
16 ft.(4.88 m) harness.
This harness connects the remote control 4 pin Molex connector to the newer
design 3 pin Packard pump trim pump connector.
MCM/MIE
