Page 713 - Latin America Accessories Guide (2020) - 8M0163252

STEERING

HEAVY DUTY TIE BAR ADD AN ENGINE KIT TIE BAR- SINGLE CYLINDER DUAL ENGINE

8M0096320 64-8M0063473
Add An Engine 26 inch Tie Bar allows triple and quad engines to be attached This tie bar can be used on a dual installation with just one cylinder. 26 inch length
together +/‑ 1.25 inches. with 1 inch of total adjustability.
Tie Bar has been engineered for higher horse power applications with improved 75‑115 HP EFI 4 Stroke OB (s/n 1B366823 & above), 150 4 Stroke, 135‑200 4
heavy duty design. cylinder Verado, OptiMax, and 3.4 & 4.6L FourStrokes up to 250hp. Use only with
26 +/‑ 1.25 inches Mercury cylinders for dual engine applications
2.6L L6 Gen 5 and 4.6L Verado Engines. 64-8M0063474
8M0096321 This tie bar can be used on a dual installation with just one cylinder. 28 inch length
Add An Engine 28 inch Tie Bar allows triple and quad engines to be attached with 1 inch of total adjustability.
together +/‑ 1.25 inches. 75‑115 HP EFI 4 Stroke OB (s/n 1B366823 & above), 150 4 Stroke, 135‑200 4
Tie Bar has been engineered for higher horse power applications with improved cylinder Verado, OptiMax, and 3.4 & 4.6L FourStrokes up to 250hp. Use only with
heavy duty design. Mercury cylinders for dual engine applications.
28 +/‑ 1.25 inches
2.6L L6 Gen 5 and 4.6L Verado Engines. 64-8M0063475
8M0096322 This tie bar can be used on a dual installation with just one cylinder. 30 inch length
with 1 inch of total adjustability.
Add An Engine 30 inch Tie Bar allows triple and quad engines to be attached 75‑115 HP EFI 4 Stroke OB (s/n 1B366823 & above), 150 4 Stroke, 135‑200 4
together +/‑ 1.25 inches. cylinder Verado, OptiMax, and 3.4 & 4.6L FourStrokes up to 250hp. Use only with
Tie Bar has been engineered for higher horse power applications with improved Mercury cylinders for dual engine applications.
heavy duty design.
30 +/‑ 1.25 inches 64-8M0063476
2.6L L6 Gen 5 and 4.6L Verado Engines. This tie bar can be used on a dual installation with just one cylinder. 32 inch length
8M0096323 with 1 inch of total adjustability.
75‑115 HP EFI 4 Stroke OB (s/n 1B366823 & above), 150 4 Stroke, 135‑200 4
Add An Engine 32 inch Tie Bar allows triple and quad engines to be attached cylinder Verado, OptiMax, and 3.4 & 4.6L FourStrokes up to 250hp. Use only with
together +/‑ 1.25 inches. Mercury cylinders for dual engine applications.
Tie Bar has been engineered for higher horse power applications with improved
heavy duty design. 64-8M0063477
32 +/‑ 1.25 inches This tie bar can be used on a dual installation with just one cylinder. 34 inch length
2.6L L6 Gen 5 and 4.6L Verado Engines. with 1 inch of total adjustability.
8M0096324 75‑115 HP EFI 4 Stroke OB (s/n 1B366823 & above), 150 4 Stroke, 135‑200 4
Add An Engine 34 inch Tie Bar allows triple and quad engines to be attached cylinder Verado, OptiMax, and 3.4 & 4.6L FourStrokes up to 250hp. Use only with
Mercury cylinders for dual engine applications.
together +/‑ 1.25 inches.
Tie Bar has been engineered for higher horse power applications with improved TIE BARS - DUAL ENGINES
heavy duty design.
34 +/‑ 1.25 inches
2.6L L6 Gen 5 and 4.6L Verado Engines.
STEERING Add An Engine 36 inch Tie Bar allows triple and quad engines to be attached
8M0097268
together +/‑ 1.25 inches.
Tie Bar has been engineered for higher horse power applications with improved
heavy duty design.
36 +/‑ 1.25 inches
2.6L L6 Gen 5 and 4.6L Verado Engines.
TIE BAR KIT- DUAL
64-892789Q22
26 Inches long with 1 inch of total adjustability.
Outboard centerline spacing of 66.0 cm (26 in.)
For use with the 75‑115 hp EFI FourStroke (s/n 1B366823 & above), 175‑200 L4
Verado, V6 OptiMax, and 3.4 & 4.6L FourStrokes ‑ Up to 600 HP dual Install with
one Counter Rotation Engine. Also used on multiple 150 4 strokes.
64-892789Q23
28 Inches long with 1 inch of total adjustability.
Outboard centerline spacing of 71.1 cm (28 in.)
For use with the 75‑115 hp EFI FourStroke (s/n 1B366823 & above), 175‑200 L4
Verado, V6 OptiMax, and 3.4 & 4.6L FourStrokes ‑ Up to 600 HP dual Install with
8M0088753 one Counter Rotation Engine. Also used on multiple 150 4 strokes.
Allows two engines to be attached together 30" to 32 " 64-892789Q25
New Tie Bar has added plating for improved protection and new retaining design 30 Inches long with 1 inch of total adjustability.
Now comes in 2 inch increments Outboard centerline spacing of 76.2 cm (30 in.)
Verado Engines 200‑300 HP and 350 SCI (5 inch maximum vertical offset For use with the 75‑115 hp EFI FourStroke (s/n 1B366823 & above), 175‑200 L4
between engines) Verado, V6 OptiMax, and 3.4 & 4.6L FourStrokes ‑ Up to 600 HP dual Install with
one Counter Rotation Engine. Also used on multiple 150 4 strokes.
