STEERING

CYLINDER - HYDRAULIC - STANDARD HYDRAULIC HELM AND CYLINDER- SMALL- STD W-O
HOSES

8M0056619
This Basic hydraulic cylinder has the same robust performance design requirement 8M0077699
as our heavy duty cylinder. It is qualified to the same 300,000 cycle as our other This kit includes a small cylinder and a new 1.2 Cubic Inch (20cc) Standard Helm.
steering systems, has high strength fasteners, stainless steel arm, with a special They do not come with hoses, you will need to order Compression Style fitting
bend for clearance, heavy duty triple seal cartridges for enhanced duribilty and hoses 8M0053474 thru 8M0053491 hose kits (1000 PSI relief).
longevity. High quality fittings using swaged compression style hose connections. Used on any brand Single Engine Outboard 150 HP and below
Mercury OB ‑ 1.5L OptiMax
HYDRAULIC HELM AND CYLINDER- SMALL- TILT W-O
HYDRAULIC HELM - BASIC SYSTEM HOSES

8M0050098
This hydraulic helm is a std 20 CC / 1.2 Cu Inch helm with compression style 8M0077701
fittings. It is used with the 8M0054993 Basic cylinder. The shaft is anodized steel This kit includes a small cylinder and a new 1.2 Cubic Inch (20cc) Tilt Helm. They
with a composite tank. The pressure relief is 1000 PSI for high torque do not come with hoses, you will need to order Compression Style fitting hoses
applicactions for improved performance. (5.2 Lock to lock wheel turns). 8M0053474 thru 8M0053491 hose kits (1000 PSI relief).
Single engine 75‑150 HP ( includes new 150 HP 4 Stroke) Used on any brand Single Engine Outboard 150 HP and below
HYDRAULIC HELM - BASIC SYSTEM CYLINDER WITH COMPRESSION STYLE FITTINGS

8M0050099 STEERING
This hydraulic helm is a Tilt 20 CC / 1.2 Cu Inch helm with compression style
fittings. It is used with the 8M0054993 Basic cylinder. The shaft is anodized steel 8M0050097
with a composite tank. The pressure relief is 1000 PSI for high torque
applicactions for improved performance. (5.2 Lock to lock wheel turns). Heavy Duty Hydraulic standard cylinder that uses compression hoses 8M0053474
‑ 8M005053491. This cylinder is tested to Mercury's rigid standards that include
Single engine 75‑150 HP OB (Includes new 150 HP 4 stroke) higher loads and cycle testing to 300,000 cycles. It includes machined, high
strength fasteners, electro polished SS arm, and heavy duty triple seal cartridges
for enhanced duribility and longevity
135‑300 HP OPTI Max Outboards and 4 Cylinder Verado (Hydraulic only) Use on
single, dual and triple installations
