STEERING

POWER STEERING HOSE KITS-JOYSTICK HYDRAULIC STEERING- MERCURY/QS
PILOTING
Hydraulic steering that is used on Verado 135‑175 engines as well as
the V6 OptiMax engines. These systems use the same hoses and
JOYSTICK PILOTING STEERING HOSES cylinders as Verado Power Steering for common applications. Also
includes Mercury's current hydraulic systems (1000 PSI) and the
Platinum Hydraulic systems for boats that exceed 60 MPH (1500 PSI).
(Cylinders used in this applicauions are 898349A01 and 898349A04)
HYDRAULIC HELM PUMP -Q/S

32-8M0078210 65.98
Kit includes two hoses of the same length (10 ft) for use on Joystick Piloting. The
hoses will route from the pump to the bulk head fitting.
Can be used on Verado 250‑350 HP and 400R Joystick installations.
JOYSTICK PILOTING HOSES
32-8M0078211 73.69 64-891665Q01 323.83
Kit includes two hoses of the same length (12 ft) for use on Joystick Piloting. The Front Mount 1.5 cu in displacement. Approximately 5 turns lock to lock on
hoses will route from the pump to the bulk head fitting. singles
Can be used on Verado 250‑350 HP and 400R Joystick installations. and 10 on dual cylinders
Compact design
Built‑in valve for positive rudder lock
32-8M0078212 81.43 Integral relief valve for over pressure protection
Kit includes two hoses of the same length (14 ft) for use on Joystick Piloting. The Hydraulic Steering for Verado 135 to 175‑4 stroke engines
hoses will route from the pump to the bulk head fitting. Also can be used on OptiMax with Mercury hydraulic cylinder and hoses. Also can
Can be used on Verado 250‑350 HP and 400R Joystick installations. be used on OptiMax with Mercury hydraulic cylinder and hoses Also can be used
32-8M0078213 89.18 on 75‑115 4 stroke and 1.5L opti 75‑115 HP
Kit includes two hoses of the same length (16 ft) for use on Joystick Piloting. The HYDRAULIC HELM PUMP -Q/S
hoses will route from the pump to the bulk head fitting.
Can be used on Verado 250‑350 HP and 400R Joystick installations.
32-8M0078214 96.94
Kit includes two hoses of the same length (18 ft) for use on Joystick Piloting. The
hoses will route from the pump to the bulk head fitting.
Can be used on Verado 250‑350 HP and 400R Joystick installations.
32-8M0078215 106.39
Kit includes two hoses of the same length (20 ft) for use on Joystick Piloting. The
hoses will route from the pump to the bulk head fitting.
Can be used on Verado 250‑350 HP and 400R Joystick installations.
32-8M0078216 114.16
Kit includes two hoses of the same length (22 ft) for use on Joystick Piloting. The 64-891665Q04 337.33
hoses will route from the pump to the bulk head fitting. STEERING
Can be used on Verado 250‑350 HP and 400R Joystick installations. Front Mount 2.0 cu in displacement. Approximately 4 turns lock to lock on
singles
32-8M0078217 121.95 and 8 on dual cylinders
Kit includes two hoses of the same length (24 ft) for use on Joystick Piloting. The Compact design
hoses will route from the pump to the bulk head fitting. Built‑in valve for positive rudder lock
Can be used on Verado 250‑350 HP and 400R Joystick installations. Integral relief valve for over pressure protection
32-8M0032520 129.75 Hydraulic Steering for Verado 135 to 200‑4 stroke engines
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses
Kit includes two hoses of same length (26 ft) for use on Joystick Piloting. The 64-891665Q05 342.52
hoses will route from the pump to the bulk head fitting.
Can be used on Verado 250‑350 HP and 400R Joystick installations. Front Mount 2.4 cu in displacement. Approximately 3 turns lock to lock on
singles
32-8M0032530 137.01 and 6.5 on dual cylinders
Kit includes two hoses of the same length (28 ft) for use on Joystick Piloting. The Compact design
hoses will route from the pump to the bulk head fitting. Built‑in valve for positive rudder lock
Can be used on Verado 250‑350 HP and 400R Joystick installations. Integral relief valve for over pressure protection
Hydraulic Steering for Verado 135 to 200‑4 stroke engines
32-8M0032547 142.20 Also can be used on OptiMax with Mercury hydraulic cylinder and hoses
Kit includes two hoses of the same length (30 ft) for use on Joystick Piloting. The
hoses will route from the pump to the bulk head fitting.
Can be used on Verado 250‑350 HP and 400R Joystick installations.
32-8M0032630 149.46
Kit includes two hoses of the same length (32 ft) for use on Joystick Piloting. The
hoses will route from the pump to the bulk head fitting.
Can be used on Verado 250‑350 HP and 400R Joystick installations.
