Page 277 - OEM RIGGING AND ACCESSORIES GUIDE (US-2017)

STEERING

CYLINDER WITH COMPRESSION STYLE FITTINGS HYDRAULIC STEERING KIT -Q/S

8M0050097 288.98 8M0073922 667.26
Heavy Duty Hydraulic standard cylinder that uses compression hoses Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses.
8M0053474 ‑ 8M005053491. This cylinder is tested to Mercury's rigid (14 ft) Approximately 5 turns lock to lock on a single engine
standards that include higher loads and cycle testing to 300,000 cycles. It Hydraulic Steering ‑ 75 HP engines and above (Use with Comptression
includes machined, high strength fasteners, electro polished SS arm, and heavy type hoses 8M0053473 thru 8M0053449)
duty triple seal cartridges for enhanced duribility and longevity
135‑300 HP OPTI Max Outboards and 4 Cylinder Verado (Hydraulic only) Use on 8M0073923 688.28
single, dual and triple installations Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses.
(16 ft) Approximately 5 turns lock to lock on a single engine
CYLINDER WITH COMPRESSION STYLE FITTINGS- Hydraulic Steering ‑ 75 HP engines and above (Use with Comptression
PORT type hoses 8M0053473 thru 8M0053449)
8M0073924 677.77
Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses.
(18 ft) Approximately 5 turns lock to lock on a single engine
Hydraulic Steering ‑ 75 HP engines and above (Use with Comptression
type hoses 8M0053473 thru 8M0053449)
8M0073925 677.77
Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses.
(20 ft) Approximately 5 turns lock to lock on a single engine
Hydraulic Steering ‑ 75 HP engines and above (Use with Comptression
type hoses 8M0053473 thru 8M0053449)
8M0073927 688.28
Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses.
8M0056145 341.52 (22 ft) Approximately 5 turns lock to lock on a single engine
Heavy Duty Hydraulic cylinder counter rotation that uses compression Hydraulic Steering ‑ 75 HP engines and above (Use with Comptression
hoses 8M0053474 ‑ 8M005053491. This cylinder is tested to Mercury's type hoses 8M0053473 thru 8M0053449)
rigid standards that include higher loads and cycle testing to 300,000
cycles. It includes machined, high strength fasteners, electro polished SS arm, and 8M0073928 693.53
heavy duty triple seal cartridges for enhanced duribility and longevity Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses.
135‑300 HP OPTI Max Outboards and 4 Cylinder Verado (Hydraulic only) Use on (24 ft) Approximately 5 turns lock to lock on a single engine
dual and triple installations (Counter rotation ) Hydraulic Steering ‑ 75 HP engines and above (Use with Comptression
type hoses 8M0053473 thru 8M0053449)
HYDRAULIC STEERING ARM
FITTING - 90 DEGREE
STEERING

898082A03 87.96
This arm attaches the cylinder to the engine for 1.5L OptiMax engines. Remove 22-8M6000760 15.05
existing arm on 898349A01 cylinder and replace it with this arm for proper 90 degree fitting used with compression style hydraulic sytems (1/4 ‑ 18 NPT to 3/8
clearances compression)
1.5L OptiMax engines Hydraulic Compression Steering systems
