Page 169 - Rigging and Accessories Guide (2022) - 8M0187689
P. 169
SMARTCRAFT RIGGING
ACTIVE TRIM SIDE MOUNT ADAPTER KIT SMARTCRAFT J-BOX TERMINATOR/RESISTOR
SMARTCRAFT RIGGING
84-8M0114502 9.78 859318T 1 8.36
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov SmartCraft Yellow 10‑pin Terminator/Resistor
Kit contains bullet to Molex connector to make Active Trim compatible with Provides CAN Bus termination for CAN P network.
mechanical side mount control TERMINATOR ASSEMBLY
Only required on boats utilizing mechanical side mount control
JUNCTION BOXES/JUNCTION BOX ACCESSORIES
SMARTCRAFT WEATHER CAP 859318A04 18.15
Terminator Assembly for CAN 1 and 3.
SMARTCRAFT J-BOX TERMINATOR/RESISTOR
859318T 2 3.84
Weather Cap for SmartCraft Junction Box
Provides weather protection at unused junction box connection points
859318B 2 3.80 859318B 1 8.32
Weather Cap for SmartCraft Junction Box SmartCraft Yellow Junction Box Terminator/Resistor
Provides weather protection at unused junction box connection points Provides CAN Bus termination where installed
Priced individually, sold @ multiples of 24 Priced individually, sold @ multiples of 24
10 PIN WEATHER CAP TERMINATOR ASSEMBLY
8M0055652 12.80
888507T 3.00
10 pin weather cap with mounting tab. SmartCraft Red Terminator Can 1/P & H
Used for harnessing that could plug into a Junction Box. TERMINATOR 10 PIN CAN V
859318T05 6.99
10 Pin terminator Can V
All Diesels
