Page 125 - Mercury Service Tool Guide (2020) - 8M0163249

FOURSTROKE MODELS

ACTUATOR ASSEMBLY TOOL DRIVESHAFT HOLDING TOOL
FOURSTROKE MODELS

91-8M0045645 91-889958T
Part of tool assembly P/N 8M0057704. Holds driveshaft during pinion nut removal.
Aids in the installation of the shift actuator rod. Used on Verado models.
ACTUATOR ASSEMBLY TOOL PINION BEARING TOOL

91-8M0057704
Aids in the installation of the shift actuator rod.
PINION HEIGHT TOOL KIT
91-8M0089163
Measures pinion gear height.
PINION HEIGHT TOOL UPGRADE KIT
91-8M0089165
Upgrades previous pinion gear locating tool kit P/N 8M0057712 to current 91-895195
P/N 8M0089163 components. Guides the removal and installation of the pinion bearing.
BEARING CUP/ADAPTER INSTALL TOOL BEARING INSTALLATION TOOL
91-8M0057767
Installs the forward gear bearing race on the standard right‑hand gear case.
Presses the reverse gear bearing adapter into the gear housing on the counter
left‑hand gear case.
BEARING CUP/ADAPTER TOOL UPGRADE KIT
91-8M0057768
Install in place of the manual release valve to measure the down pressure in the
power trim system.
BEARING DRIVER TOOL
91-8M0062360
Removes pinion bearing from gear housing.
91-895195T01
SHIMMING PLATE Aids in the installation of bearings into the gearcase.
BACKLASH PRELOAD TOOL

91-8M0116860
Prevents forward gear movement when checking the forward gear backlash.
PINION HEIGHT TOOL
91-895218
Aids in determining the pinion gear height.
91-889586
Fixture used to shim the forward gear. (Stamped 06701)
