BRAVO STERNDRIVE

BRAVO STERNDRIVE TOOLS BEARING CARRIER WRENCH

HEX NUT

91- 17257T
Spool retainer ‑ bearing carrier.
ADJUSTMENT TOOL

11- 24156
.625‑18 Hex nut that aids in the removal and installation of various drive
components. May use with puller shaft (P/N 31229). Included in the bearing
removal and installation kit (P/N 31229A7).
WASHER

91- 17262A 1 BRAVO STERNDRIVE
Cable shift adjustment tool. Includes Core Wire Locating Tool (P/N 17263) and
Shift Cable Anchor Adjustment Tool (P/N 17262).
Use to set the shift cable adjustments after shift cable installation.
BUSHING REMOVAL TOOL
12- 34961
.656 x 1.312 x .095, plain.
Used on the threaded puller rod between the nut and plate when removing
bearings.
PRELIMINARY SHIFT ADJUSTMENT TOOL

91- 12427T
Attaches over the shift cable and aids in proper shift cable adjustment at the shift 91- 17273
plate. Aids in the removal of the shift shaft bushing.
For MCM Bravo One and Bravo Two models.
BEARING AND SEAL DRIVER TOOL
U-JOINT RETAINER WRENCH

91- 17275A 1
91- 17256 Installation of gear housings dearing and seal.
Installs and torques the U‑Joint retainer nut.

Mercury Service Tool Guide 13
