HISTORICAL PROPELLER CHARTS

Part No. Diameter Pitch Material Blades Rotation Status or Supersession
96627M 9-1/4 8 AL 3 RH NLA
82767 9-1/4 7 AL 3 RH NLA
96628M 9-1/4 7 AL 3 RH NLA
96630M 9-1/4 5 AL 3 RH NLA
Mariner 20 (6A9), 25 (690/695), 28 (664), 30 (689)
With Thru Hub Exhaust
NLA = 48‑80262M
Nut 11‑81774M Cotter Pin 18‑82132M Thrust Hub (Fwd) 859917
20/25/30 ‑ Thrust Hub (Rear) 859895 Spacer 85905
28 ‑ Thrust Hub (Rear) 23‑82796M (NLA) Spacer 23‑81651M
Part No. Diameter Pitch Material Blades Rotation Status or Supersession
84977M 9-7/8 14 AL 3 RH AVAIL.
82827M 9-7/8 13 AL 3 RH
QA3814T 9-7/8 13 AL 3 RH
82826M 9-7/8 12 AL 3 RH QA3810R
88168A4 9 12 SS 3 RH NLA
84976M 9-7/8 11-1/4 AL 3 RH QA3810R
81649M 9-7/8 10-1/2 AL 3 RH QA3808R
81647M 9-7/8 9 AL 3 RH AVAIL.
88166A4 10 9 SS 3 RH NLA
81648M 9-7/8 8 AL 3 RH AVAIL.
Mariner 20 & 25 S/N 6535603 and Above
Standard
Thrust Hub 858498 Hub 11‑88228
Chopper
Thrust Hub 858498 Hub 11‑88228

Part No. Diameter Pitch Material Blades Rotation Status or Supersession
Standard
4590A40 10-1/4 14-1/2C AL 3 RH
89854A 4 10-1/4 14-1/2C AL 3 RH
19642A40 10-3/8 14-1/2C AL 3 RH AVAIL.
43586A40 10-3/8 13C AL 3 RH 48- 19640A40
86848A 4 10-3/8 13C AL 3 RH 48- 19640A40
19640A40 10-3/8 13C AL 3 RH AVAIL.
43588A 5 10-3/8 13C SS 3 RH 48- 19644A 5
90780A 4 10-3/8 13C SS 3 RH 48- 19644A 5
19644A 5 10-3/8 13C SS 3 RH AVAIL.
43584A40 10-3/8 11C AL 3 RH 48- 19638A40
89852A 4 10-3/8 11C AL 3 RH 48- 19638A40
19638A40 10-3/8 11C AL 3 RH AVAIL.
43582A10 10-3/8 9-1/2 AL 3 RH 48- 19636A10
89850A 1 10-3/8 9-1/2 AL 3 RH 48- 19636A10
19636A10 10-3/8 9-1/2C AL 3 RH AVAIL.
Chopper
92764A 4 10-3/8 18C SS 3 RH N.L.A.
92764A 5 10-3/8 18C SS 3 RH N.L.A.
43592A 5 10-3/8 18C SS 3 RH N.L.A.
