Page 31 - Mercury Propeller Guide (2021) - 8M0174460
P. 31
MERCURY PROPELLER RIGGING CHART
Diameter Pitch No. of Blades Boat Weight Boat Speed RH - Part Number Description LH - Part Number Performance
Category
14.6 18 4 3400-3800 48-54 48-8M0151319 Revolution 4 48-8M0151318 Comp Series
14.6 17 4 3500-4100 45-52 48-8M0151317 Revolution 4 48-8M0151316 Comp Series
14.6 15 4 4100-5500 35-45 48-8M0151315 Revolution 4 48-8M0151314 Comp Series
14.5 25 3 2200-2500 69-78 48-8M0151313 Mirage Plus Elite Series
14.6 23 3 2500-2800 63-71 48-8M0151312 Mirage Plus 48-8M0151311 Elite Series
14.8 21 3 2800-3200 57-64 48-8M0151310 Mirage Plus 48-8M0151309 Elite Series
15.3 19 3 3100-3600 51-58 48-8M0151308 Mirage Plus 48-8M0151307 Elite Series
15.5 17 3 3500-4100 45-52 48-8M0151304 Mirage Plus 48-8M0151303 Elite Series
15.8 15 3 4100-5500 35-45 48-8M0151302 Mirage Plus 48-8M0151301 Elite Series
Pro FourStroke 200 HP ‑ V6 ‑ Tri / Pontoon
Engine RPM Range: 5800 ‑ 6400 Gearcase Ratio 1.85:1
Diameter Pitch No. of Blades Boat Weight Boat Speed RH - Part Number Description Performance Category
13.8 20 3 2750-2950 54-63 48-8M0151241 Enertia Comp Series
14 19 3 2800-3200 51-58 48-8M0151239 Enertia Comp Series
14.2 18 3 2950-3450 47-55 48-8M0151237 Enertia Comp Series
14.5 17 3 3100-3700 45-52 48-8M0151235 Enertia Comp Series
14.7 16 3 3350-4250 41-50 48-8M0151233 Enertia Comp Series
15 15 3 3600-4400 38-47 48-8M0151231 Enertia Comp Series
15.3 14 3 3900-5200 35-43 48-8M0151229 Enertia Comp Series
15.6 13 3 4100-5800 31-40 48-8M0151227 Enertia Comp Series
16 11 3 6000+ 1-29 48-8M0151225 Enertia Comp Series
14 23 3 2200-2500 63-71 48-8M0084497 SpitFire Elite Series
14 21 3 2500-2800 57-64 48-8M0084496 SpitFire Elite Series
14 19 3 2800-3200 51-58 48-8M0084495 SpitFire Elite Series
14 17 3 2200-2500 63-71 48-8M0084494 SpitFire Elite Series
14 14 3 3900-5200 35-43 48-8M0084493 SpitFire Elite Series
14 12 3 4900-6800 26-35 48-8M0084491 SpitFire Elite Series
14.3 21 3 2500-2800 57-64 48-832832A45 Black Max Sport Series
14.5 19 3 2800-3200 51-58 48-832830A45 Black Max Sport Series
15 17 3 3100-3700 45-52 48-832828A45 Black Max Sport Series
14.5 19 3 2800-3200 51-58 48-832830A45 Black Max Sport Series
15 17 3 3100-3700 45-52 48-832828A45 Black Max Sport Series
15.3 15 3 3600-4400 38-47 48- 78116A45 Black Max Sport Series
16 13 3 4100-5800 31-40 48- 78114A45 Black Max Sport Series
Verado 200 HP – 4Cyl ‑ Tri / Pontoon
Engine RPM Range: 5800‑6400 Gearcase Ratio: 1.85:1
Diameter Pitch No. of Blades Boat Weight Boat Speed RH - Part Number Description Performance Category
14 19 3 3300-3900 43-50 48-8M0151239 Enertia Comp Series
14.2 18 3 3500-4300 39-47 48-8M0151237 Enertia Comp Series
14.4 17 3 3800-4700 36-44 48-8M0151235 Enertia Comp Series
14.7 16 3 4100-5200 33-41 48-8M0151233 Enertia Comp Series
15 15 3 4400-6000 29-38 48-8M0151231 Enertia Comp Series
15.3 14 3 4900-6800 26-35 48-8M0151229 Enertia Comp Series
15.6 13 3 5400-8200 22-32 48-8M0151227 Enertia Comp Series
16 11 3 6000+ 1-25 48-8M0151225 Enertia Comp Series
15.3 19 3 3300-3900 43-50 48-8M0084496 SpitFire Elite Series
15.5 17 3 3800-4700 36-44 48-8M0084494 SpitFire Elite Series
15.8 14 3 3600-4400 29-38 48-8M0084493 SpitFire Elite Series
16 12 3 5400-8200 22-32 48-8M0084491 SpitFire Elite Series
15.3 19 3 3300-3900 43-50 48-832830A45 Black Max Sport Series
15.5 17 3 3800-4700 36-44 48-832828A45 Black Max Sport Series
15.3 15 3 3600-4400 29-38 48- 78116A45 Black Max Sport Series
