Page 32 - Mercury Propeller Guide (2021) - 8M0174460
P. 32
MERCURY PROPELLER RIGGING CHART
Diameter Pitch No. of Blades Boat Weight Boat Speed RH - Part Number Description Performance Category
16 13 3 5400-8200 22-32 48- 78114A45 Black Max Sport Series
16 11 3 6000+ 1-25 48- 78112A45 Black Max Sport Series
150 HP FourStroke ‑ Tri / Pontoon
Engine RPM Range: 5000‑5800 Gearcase Ratio: 1.92:1
Diameter Pitch No. of Blades Boat Weight Boat Speed RH - Part Number Description Performance Category
13.5 22 3 2100-2600 47-57 48-8M0151245 Enertia Comp Series
13.6 21 3 2200-2800 44-54 48-8M0151243 Enertia Comp Series
13.8 20 3 2300-3000 42-52 48-8M0151241 Enertia Comp Series
14 19 3 2500-3200 39-49 48-8M0151239 Enertia Comp Series
14.3 18 3 2700-3200 35-46 48-8M0151237 Enertia Comp Series
14.5 17 3 2900-4000 32-43 48-8M0151235 Enertia Comp Series
14.8 16 3 3100-4500 29-40 48-8M0151233 Enertia Comp Series
15 15 3 3400-5100 26-37 48-8M0151231 Enertia Comp Series
15.3 14 3 3800-6200 22-34 48-8M0151229 Enertia Comp Series
15.6 13 3 4500-7000 1-28 48-8M0151227 Enertia Comp Series
16 11 3 7000+ 1-25 48-8M0151225 Enertia Comp Series
14 19 4 2500-3200 39-49 48-8M0084495 SpitFire Elite Series
14 17 4 2900-4000 32-43 48-8M0084494 SpitFire Elite Series
14 14 4 3800-6200 22-34 48-8M0084493 SpitFire Elite Series
14 12 4 7000+ 1-25 48-8M0084491 SpitFire Elite Series
14.5 19 3 2500-3200 39-79 48-832830A45 Black Max Sport Series
15 17 3 2900-4000 32-43 48-832828A45 Black Max Sport Series
15.3 15 3 3400-5100 26-37 48- 78116A45 Black Max Sport Series
16 13 3 4500-7000 1-28 48- 78114A45 Black Max Sport Series
16 11 3 7000+ 1-25 48- 78112A45 Black Max Sport Series
115 CT HP FourStroke ‑ Tri / Pontoon
Engine RPM Range: 5000‑6000 Gearcase Ratio: 2.38:1
Diameter Pitch No. of Blades Boat Weight Boat Speed RH - Part Number Description Performance Category
13.5 22 3 2000-2800 35-47 48-8M0151245 Enertia Comp Series
13.8 21 3 2100-3100 32-45 48-8M0151243 Enertia Comp Series
13.8 20 3 2300-3500 29-42 48-8M0151241 Enertia Comp Series
14 19 3 2400-3700 27-40 48-8M0151239 Enertia Comp Series
14.2 18 3 2600-4300 24-37 48-8M0151237 Enertia Comp Series
14.5 17 3 2800-5000 21-35 48-8M0151235 Enertia Comp Series
14.7 16 3 3100-5600 19-32 48-8M0151233 Enertia Comp Series
15 15 3 3500-6700 16-29 48-8M0151231 Enertia Comp Series
15.3 14 3 3900-7800 14-26 48-8M0151229 Enertia Comp Series
15.6 13 3 4300-10300 11-24 48-8M0151227 Enertia Comp Series
16 11 3 7000+ 1-18 48-8M0151225 Enertia Comp Series
14 23 4 1900-2600 38-49 48-8M0084497 SpitFire Elite Series
14 21 4 2100-3100 32-45 48-8M0084496 SpitFire Elite Series
14 19 4 2400-3700 27-40 48-8M0084495 SpitFire Elite Series
14 17 4 2800-5000 21-35 48-8M0084494 SpitFire Elite Series
14 14 4 3900-7800 14-26 48-8M0084493 SpitFire Elite Series
14 12 4 7000+ 1-24 48-8M0084491 SpitFire Elite Series
14.5 19 3 2400-3700 27-40 48-832830A45 Black Max Sport Series
15 17 3 2800-5000 21-35 48-832828A45 Black Max Sport Series
15.3 15 3 3500-6700 16-29 48- 78116A45 Black Max Sport Series
16 13 3 4300-10300 11-24 48- 78114A45 Black Max Sport Series
16 12 3 5000+ 9-21 48- 16436A45 Black Max Sport Series
16 11 3 7000+ 1-18 48- 78112A45 Black Max Sport Series
2021 Mercury Propeller Guide 25
