Page 75 - REPOWER REFERENCE GUIDE (2020)

Propeller Selection

Plus Series ‑ 496 HO Bravo ‑ (425 HP) ‑ V8 Bravo One X
Quicksilver Propellers ‑ For Twin Engine Boats
WOT: 4800–5200 RPM, Standard Gear Ratio 1.50:1
High Altitude (1524 m [5000 ft])+ Gear Ratio: 1.65:1
Right and Left‑Hand Rotation Required for Twins
Approximate Gross Boat
Diameter Pitch Blades Material Approximate Boat Length Speed Range
Weight
40 cm 38.1 cm 6532–8573 kg 9.8–11 m 55–69 kph
(15.75 in.) (15 in.) 3 Stainless Steel (14400–18900 lb) (32–36 ft) (34–43 mph)
39.4 cm 43.2 cm 3 Stainless Steel 5488–6713 kg 9.5–10.1 m 66–79 kph
(15.5 in.) (17 in.) (12100–14800 lb) (31–33 ft) (41–49 mph)
38.7 cm 48.3 cm 4717–5625 kg 9.1–9.8 m 76–89 kph
(15.25 in.) (19 in.) 3 Stainless Steel (10400–12400 lb) (30–32 ft) (47–55 mph)
37.5 cm 55.3 cm 3 Stainless Steel 4082–4808 kg 8.5–9.5 m 85–98 kph
(14.75 in.) (21 in.) (9000–10600 lb) (28–31 ft) (53–61 mph)
37.2 cm 58.4 cm 3583–4173 kg Up to 8.8 m 95–106 kph
(14.63 in.) (23 in.) 3 Stainless Steel (7900–9200 lb) (29 ft) (59–66 mph)

Plus Series ‑ 496 HO Bravo ‑ (425 HP) ‑ V8 Bravo Three X
Quicksilver Propellers ‑ For Twin Engine Boats
WOT: 4600–5000 RPM, Standard Gear Ratio 1.81:1
High Altitude (1524 m [5000 ft])+ Gear Ratio: 2.00:1
Approximate Gross Boat
Diameter Pitch Blades Material Approximate Boat Length Speed Range
Weight
40.6 cm 50.8 cm 5715–7031 kg 9.5–10.1 m 64–76 kph
(16 in.) (20 in.) 3 Stainless Steel (12600–15500 lb) (31–34 ft) (40–47 mph)
36.5 cm 50.8 cm 3 Stainless Steel 5715–7031 kg 9.5–10.1 m 64–76 kph
(14.38 in.) (20 in.) (12600–15500 lb) (31–34 ft) (40–47 mph)
40 cm 55.9 cm 5039–5897 kg 9.1–9.8 m 72–84 kph
(15.75 in.) (22 in.) 3 Stainless Steel (11100–13000 lb) (30–32 ft) (45–52 mph)
36.2 cm 55.9 cm 3 Stainless Steel 5039–5897 kg 9.1–9.8 m 72–84 kph
(14.25 in.) (22 in.) (11100–13000 lb) (30–32 ft) (45–52 mph)
39.4 cm 61 cm 4445–5171 kg 8.8–9.5 m 80–92 kph
(15.5 in.) (24 in.) 3 Stainless Steel (9800–11400 lb) (29–31 ft) (50–57 mph)
36.2 cm 61 cm 4445–5171 kg 8.8–9.5 m 80–92 kph
(14.25 in.) (24 in.) 3 Stainless Steel (9800–11400 lb) (29–31 ft) (50–57 mph)
38.7 cm 66 cm 3 Stainless Steel 3946–4536 kg 8.5–9.1 m 89–100 kph
(15.25 in.) (26 in.) (8700–10000 lb) (28–30 ft) (55–62 mph)
35.6 cm 66 cm 3946–4536 kg 8.5–9.1 m 89–100 kph
(14 in.) (26 in.) 3 Stainless Steel (8700–10000 lb) (28–30 ft) (55–62 mph)
38.1 cm 71.1 cm 3 Stainless Steel 3538–4037 kg Up to 8.8 m 97–108 kph
(15 in.) (28 in.) (7800–8900 lb) (29 ft) (60–67 mph)
34.9 cm 71.1 cm 3538–4037 kg Up to 8.8 m 97–108 kph
(13.75 in.) (28 in.) 3 Stainless Steel (7800–8900 lb) (29 ft) (60–67 mph)

90-8M0149179 eng NOVEMBER 2018 © 2019 Mercury Marine Page 4B-27
