316 STAINLESS STEEL QBNV SERIES ISO B

• 316 Stainless Steel
• Conforms to ISO 7241-1 Series B
• Viton Seals

Part No Body Description Connection Working
Size Pressure
(“) (Bar)
QBNVS-F04 1/4 Coupler 1/4” BSPPF 320
QBNVS-M04 1/4 Nipple 1/4” BSPPF 320
QBNVS-F06 3/8 Coupler 3/8” BSPPF 260
QBNVS-M06 3/8 Nipple 3/8” BSPPF 260
QBNVS-F08 1/2 Coupler 1/2” BSPPF 260
QBNVS-M08 1/2 Nipple 1/2” BSPPF 260
QBNVS-F12 3/4 Coupler 3/4” BSPPF 210
QBNVS-M12 3/4 Nipple 3/4” BSPPF 210
QBNVS-F16 1 Coupler 1” BSPPF 210
QBNVS-M16 1 Nipple 1” BSPPF 210
QBNVS-F20 1.1/4 Coupler 1.1/4” BSPPF 100
QBNVS-M20 1.1/4 Nipple 1.1/4” BSPPF 100
QBNVS-F24 1.1/2 Coupler 1.1/2” BSPPF 100
QBNVS-M24 1.1/2 Nipple 1.1/2” BSPPF 100
QBNVS-F32 2 Coupler 2” BSPPF 100
QBNVS-M32 2 Nipple 2” BSPPF 100

QBNV SERIES
DUST CAPS AND PLUGS

Part No Body Description Material
Size (“)
QBNV-DC02 1/8 Cap Plastic
QBNV-DC04 1/4 Cap Plastic
QBNV-DC06 3/8 Cap Plastic
QBNV-DC08 1/2 Cap Plastic
QBNV-DC12 3/4 Cap Plastic
QBNV-DC16 1 Cap Plastic
QBNV-DP02 1/8 Plug Plastic
QBNV-DP04 1/4 Plug Plastic
QBNV-DP06 3/8 Plug Plastic
QBNV-DP08 1/2 Plug Plastic
QBNV-DP12 3/4 Plug Plastic
QBNV-DP16 1 Plug Plastic

***NOTE** See Page J21 for technical details
