Swing Joints and Risers
Code Description
TORO SWING JOINTS & ADAPTORS (SCHEDULE 80 / CLASS 18) 1800 KPA RATING THREADING BY DURA
TSJ-10B-12-3-10A 300 mm x 25 mm Articulated Riser BSP x ACME Male Thread
TSJ-10B-12-3-10B 300 mm x 25 mm Articulated Riser BSP x BSP Male Thread (prevously DU2010BSP)
TSJ-10S-12-3-10A 300 mm x 25 mm Articulated Riser Slip x ACME Male Thread
TSJ-10S-12-3-10B 300 mm x 25 mm Articulated Riser Slip x BSP Male Thread (prevously DU2010SLIP)
TSJ-10B-12-3-10M 300 mm x 25 mm Articulated Riser BSP x Male Iron Pipe Threaad
TSJ-15B-12-3-15A 300 mm x 40 mm Articulated Riser BSP x ACME Male Thread
TSJ-15B-12-3-15B 300 mm x 40 mm Articulated Riser BSP x BSP Male Thread (prevously DU2015BSP)
TSJ-15S-12-3-15A 300 mm x 40 mm Articulated Riser Slip x ACME Male Thread
TSJ-15S-12-3-15B 300 mm x 40 mm Articulated Riser Slip x BSP Male Thread (prevously DU2015SLIP)
TSJ-15B-12-3-15M 300 mm x 40 mm Articulated Riser BSP x Male Iron Pipe Thread (prevously DU2015MPT)
TOBA39-010 25 mm BSP to ACME Adaptor
TOBA39-015 40 mm BSP to ACME Adaptor
SWING JOINTS SPEARS (SCHEDULE 80) 3 ELBOW 1800 KPA RATING
5893-01010-A 300 mm x 25 mm Articulated Riser BSP x BSP
5893-01510-A 300 mm x 40 mm Articulated Riser BSP x BSP
5895-01010-A 300 mm x 25 mm Articulated Riser Slip x BSP
5895-01510-A 300 mm x 40 mm Articulated Riser Slip x BSP
TORO SUPER FUNNY PIPE FLEX ASSEMBLIES 600 KPA RATING
SPFA-585 200 mm x 15 mm x 15 mm BSP Articulated Riser

SPFA-5875 200 mm x 15 mm x 20 mm BSP Articulated Riser
SPFA-5125 300 mm x 15 mm x 15 mm BSP Articulated Riser
SPFA-51275 300 mm x 15 mm x 20 mm BSP Articulated Riser
ARTICULATED RISERS (POLYPROPYLENE 700 KPA RATING
591-025 200 mm x 15 mm BSP Articulated Risers (3 Elbow)
591-027 300 mm x 15 mm BSP Articulated Risers (3 Elbow)
591-029 200 mm x 20 mm BSP Articulated Risers (3 Elbow)
591-030 300 mm x 20 mm BSP Articulated Risers (3 Elbow)
591-032 200 mm x 25 mm BSP Articulated Risers (3 Elbow)
591-034 300 mm x 25 mm BSP Articulated Risers (3 Elbow)
ARTICULATED RISERS (POLYPROPYLENE 700 KPA RATING
G465-312 300 mm x 50 mm Articulated Riser BSPM x 135 BSPM (3 Elbow)
ELBOWS (POLYPROPYLENE) MALE X FEMALE 700 KPA RATING
591-MFE15 15 mm BSP Elbow, Male x Female
591-MFE20 20 mm BSP Elbow, Male x Female
591-MFE25 25 mm BSP Elbow, Male x Female
