Solenoid Coils and Accessories

588403
• 811B Solenoid Assembly
• 24VAC, 50Hz, 0.34 amp inrush, 0.20 amp holding current
• 45cm Red leads, XLPE insulation, 20AWG conductors
• Captive plunger

DCLS-P
• Potted DC Latching solenoid suits EZ-Flo Plus, P-150, P-220
and 220 series valves. Suits DDCWP
• Wetted parts constructed from 400 stainless steel and zytel
• Voltage: 6-14VDC
• Coil resistance: 9 ohms
• Coil inductance: 65 mH
• Pulse width: 20ms
• Leads: 2, red and black, 45cm long, 20AWG, PVC insulation
• Latch position: + Red and - Black
• Unlatch position: + Black and - Red

HVC-KIT
• Converts standard solenoid operated valve into hydraulic
remotely operated valve. Only suits Toro P150, P220, Irritrol
Century, Century Plus and S-Series solenoid valves
• Kit consists of a thread x ¼” barbed adaptor (to replace the
coil) and 2 PVC plugs. Suits Toro ¼” control tubing
• Cannot be used if EZReg or OmniReg required or fitted

Lilac Valve Accessories

1088501
• Effluent tag for use with Toro or competitive valves

Air Vacuum Breaker – 15 mm MBSP

Air Intake vs Vacuum Pressure
Application Vacuum Pressure -10 -20 -30 -40
Designed to allow air into the irrigation (kPa)
system, under vacuum conditions created
during shutdown and drainage of drip lines. Air Intake (m3/h) 34 51 65 80
Aids in the prevention of dirt ingress into
drippers under vacuum.

Specifications

• 15mm (½”) BSPM thread
• Maximum pressure: 1000 kPa
• Plastic construction with Ordering Information
Buna-N o-ring seal
Code Description
101VB15 Air vacuum Breaker, 15mm BSPM
Pack size: 20
