Fundamentals of Stress and Vibration 2. Engineering Mechanics Chapter
[A Practical guide for aspiring Designers / Analysts]

‘ŽŽ‘™‹‰ ‹• ƒ •—ƒ”‹œ‡† –ƒ„—Žƒ–‹‘ ˆ‘” Ž‹‡ƒ” ƒ† ƒ‰—Žƒ” ‡“—ƒ–‹‘• ‘ˆ ‘–‹‘Ǥ

Linear quantities Angular quantities

2
2
V = u + 2as Ω = ω + 2αθ
2
2
V = u + at Ω = ω + at

1 1
2
s = ut + at θ = ωt + αt
2
2 2
Where,

V Final velocity Ω Final angular velocity

u Initial velocity ω Initial Angular velocity

a Acceleration α Angular acceleration

t Time θ Angular displacement

s Displacement

Example 4 (Basic Optimization): Consider a cannon firing a ball, as shown in [Fig 2.19].
What is the optimum angle θ and height (H), with which, the ball must be fired such that it hits
the target?
Parameters of the problem are as tabulated.

Parameters Magnitude

Velocity of fire (V) 25 m/s

Limits of variable height (H) 40m to 80m

Limits of angle of projection (θ) 30° to 40°

Horizontal displacement of bullet (L) 100 m

Acceleration due to gravity (g) 10 m/s
2
0
The accuracy of angle in the final solution must be within ±0.1 .
