Self-Reflection
Self-Reflection SCAN ME CHAPTER 5
Download and print
Self-Reflection Electronics
1. New things I have learnt in the chapter on ‘Electronics’
are ✎ .
https://bit.ly/34Prhyj
2. The most interesting thing I have learnt in this chapter
KEMENTERIAN PENDIDIKAN MALAYSIA
is ✎ .

3. The things I still do not fully understand are ✎ .
4. My performance in this chapter.

Poor 1 2 3 4 5 Very good

5. I need to ✎ to improve my performance in this chapter.

https://bit.ly/
Summative Practice 2YUeNSh

1. (a) Using appropriate electronic symbols, draw a forward biased semiconductor diode in an
electronic circuit.
(b) What will happen if the battery connection in 1(a) is reversed?

2. Figure 1 shows a half-wave rectification kit connected to an alternating current power
supply and a cathode ray oscilloscope (C.R.O.).

Diode

Alternating
current R to C.R.O.
power supply

Figure 1
(a) Sketch what is displayed on the cathode ray oscilloscope screen.
(b) If a capacitor is connected in parallel with the resistor, R, sketch the changes to what is
displayed on the cathode ray oscilloscope screen.
