CONTENTS

<Diesel Engine>
1. GENERAL ------------------------------------------------------------------ 1-1 / 1-8
(1) Major Operational Characteristics
(2) Operating Process
(3) Features of Diesel Engine
(4) Combustion Chamber
(5) Combustion Process
(6) Diesel Knocking
(7) Diesel Fuel
(8) Knowledge Check

2. TECHNICAL FEATURES OF 4D56 ENGINE --------------------- 2-1 / 2-3
(1) Major Specifications
(2) Technical Features
(3) Knowledge Check

3. FUEL SYSTEM ------------------------------------------------------------ 3-1 / 3-7
(1) General
(2) Specifications
(3) Common Rail
(4) Fuel Tank
(5) Knowledge Check

4. SERVICE POINTS OF 4D56 ENGINE COMPONENT ---------- 4-1 / 4-13
(1) On-Vehicle Inspection & Service
1) Compression Pressure Check
2) Timing Belt “B” Installation
3) Timing Belt installation
4) Common Rail Installation
5) Injector Installation
6) Valve Clearance Adjustment

(2) Engine Overhaul
1) Cylinder Head gasket Installation
2) Cylinder Head Bolt Installation
3) Assembly of Connecting Rod and Piston
4) Connecting Rod Cap Installation
5) Crankshaft Bearing Installation
6) Bearing Cap Installation
