Power Vises and Fixturing Systems

Quick-Change
Five-Axis Workholding

Accurate and versatile fixture for round, square,
and hex-shaped workpieces. Mounts vertically
or horizontally, and uses standard 5C collets.
Advanced workpiece-release mechanism for
flawless operation. Far better accuracy and
repeatability than competitive collet vises.
®
CL5 Quick-Change Workpiece is pulled solidly against the bottom stop
Five-Axis Workholding for excellent height repeatability.
pages 675-681

Fixture Clamps

Fixture clamps consist of a very compact body
with integrated hydraulic cylinders that actuate
the movable jaw. All threads and ports are at the
bottom which allows for a very tight and space
With Fixed Jaw savings arrangement. Accessory blank jaws are
page 685 also available that can be milled to match the
workpiece contour.

Concentric
page 686

Position Flexible
page 687 14
