Vises Fixture Clamps I4.110 & I4.111
J
J
Fixture Clamps with Fixed Jaw Compact vise with jaw widths 1.57" and 2.56"
J
Double Acting Max. Operating Pressure 3625 psi (250 bar)
J
J
The fixed jaw fixture clamp consists of a very mounting or tube connection is available.
compact body with an integrated hydraulic Accessory blank jaws are also available
cylinder that actuates the movable jaw. All that can be milled to match the workpiece
threads and ports are at the bottom which contour. The fixed jaw can be equipped with a
allows for a very tight and space savings pneumatic seat control which is well suited for
arrangement. If fastening from the bottom automation applications.
is not possible an adaptor plate for manifold

Intermediate piece
or clamping jaw
Stroke
Fixed jaw Clamping jaw

Blank jaws and cap screws
sold separately.

D
Fixing from above
with accessory adaptor plate
Drilled channels

Application example C
Clamping fixture for a pedal of a
freight vehicle.

B
A

Fixing from below
Drilled channels

Jaw Width (in.) 1.57 2.56
Stroke (in.) 0.20 1.18 0.20 1.77
3625 psi 2135 2135 3370 3370
Clamp Force 2000 psi 1180 1180 1860 1860
(lbs)
1000 psi 600 600 930 930
A (in.) 1.57 1.57 2.56 2.56
Connecting insert
B (in.) 4.13 6.10 6.30 9.45
Fitting connection C (in.) 2.17 2.17 2.56 2.56
D (in.) 0.71 0.71 1.06 1.06
Optional Weight (lbs.) 3.66 4.94 11.13 15.43
mounting Part No. CLR-4413-001 CLR-4413-031 CLR-4413-101 CLR-4413-131
mlate or tubing
connection
-G1/8 Accessories
Part No., Adapter Mounting Plate CLR-0441-300 CLR-0441-303 CLR-0441-310 CLR-0441-313
Part No., Blank Clamping Jaw CLR-3548-070 CLR-3548-070 CLR-3548-080 CLR-3548-080
Part No., Blank Fixed Jaw CLR-3548-071 CLR-3548-071 CLR-3548-081 CLR-3548-081
Part No., Jaw Screws CLR-3301-107 CLR-3301-107 CLR-3300-700 CLR-3300-700 14

Subject to change. For further details, including detailed dimensions and mounting instructions, visit roemheld-usa.com.
