Vises Fixture Clamps I4.130
J
J
Fixture Clamps, Position Flexible Compact vise with jaw width 1.57"
J
Double Acting Max. Operating Pressure 3625 psi (250 bar)
J
J
The position flexible fixture clamp consists of along with the clamping force. All threads
a very compact body with integrated hydraulic and ports are at the bottom which allows for
cylinders that actuate the movable jaws. The a very tight and space savings arrangement.
piston forces are transmitted via two channels If fastening from the bottom is not possible an
to the clamping slides. The design allows the adaptor plate for manifold mounting or tube
clamping slides to move independently of connection is available. Accessory blank jaws
each. A minimal contact force is applied to are also available that can be milled to match
the part until both jaws are in contact with the the workpiece contour.
workpiece. At that point the pressure builds

Stroke Clamping Clamping Stroke
jaw jaw
Application example
Clamping fixture for a pedal of a freight vehicle.

Fixing from above
with accessory adaptor plate D
Drilled channels

Blank jaws and cap screws
sold separately.

D

C
Clamping principle
Fixing from below Position-flexible
Drilled channels fixture clamp
B
A

Jaw Width (in.) 1.57
Fixture clamp with fixed jaw Stroke per Jaw (in.) 0.31
3625 psi 1800
Clamp Force
Connecting insert per Jaw (lbs) 2000 psi 990
1000 psi 495
A (in.) 1.57
Pipe thread B (in.) 6.10
C (in.) 2.17
D (in.) 0.71
Optional mounting plate Weight (lbs.) 5.51
for tubing connection Part No. CLR-4413-080
-G1/8
Accessories
Part No., Adapter Mounting Plate CLR-0441-305
Part No., Blank Clamping Jaw CLR-3548-070
14
Part No., Jaw Screws CLR-3301-107

Subject to change. For further details, including detailed dimensions and mounting instructions, visit roemheld-usa.com.
