Vises Fixture Clamps I4.120
J
J
Fixture Clamps, Concentric Compact vise with jaw widths 1.57" and 2.56"
J
Double Acting Max. Operating Pressure 3625 psi (250 bar)
J
J
The concentric fixture clamp consists of a very which allows for a very tight and space savings
compact body with two integrated hydraulic arrangement. If fastening from the bottom is
cylinders that actuate the movable jaws. The not possible an adaptor plate for manifold
piston forces are transferred to a “V” linkage mounting or tube connection is available.
(see cut away below). The “V” linkage then Accessory blank jaws are also available that
pulls the jaws together in a self-centering can be milled to match the workpiece contour.
fashion. All threads and ports are at the bottom

Stroke Clamping Clamping Stroke
jaw jaw

Fixing from above
with accessory adaptor plate
Drilled channels
Blank jaws and cap screws
sold separately.
Application example
Clamping fixture for a pedal of a
freight vehicle.

Fixing from below
Drilled channels

Jaw Width (in.) 1.57 2.56
Stroke per Jaw (in.) 0.20 0.31
Repeatability +/- 0.0008 0.0008
3625 psi 1460 2025
Clamp Force per Jaw 2000 psi 805 1115
(lbs)
1000 psi 405 560
Connecting insert A (in.) 1.57 2.56
B (in.) 6.10 7.87
Fitting connection Optional C (in.) 2.17 2.56
mounting plate D (in.) 0.71 1.10
for tubing Weight (lbs.) 5.29 13.23
connection
-G1/8 Part No. CLR-4413-051 CLR-4413-151

Accessories
Part No., Adapter Mounting Plate CLR-0441-305 CLR-0441-315
Part No., Blank Clamping Jaw CLR-3548-070 CLR-3548-080
14
Part No., Jaw Screws CLR-3301-107 CLR-3300-625

Subject to change. For further details, including detailed dimensions and mounting instructions, visit roemheld-usa.com.
