Page 693 - CarrLaneCatalog_2019ed-c.pdf

Electric Power Units 7250/5000 psi max
Multi-Pressure in single and double acting

• Complete power unit with electrical and SET-UP SUMMARY: Connect to fused
hydraulic controls electrical supply, fill with oil, and connect to
• Enclosed fan-cooled single or three fixture. Prime pump and adjust to desired
phase motor with thermal protection pressure. Mount push button switch(es) near
the operator. Push one button to clamp and
• Combination temperature/ level switch unclamp. For complete set-up instructions,
for pump protection see operating manual.
• Remote clamp-unclamp push button
switch(es) OPERATING PRINCIPLES: The heart of
• Pressure adjustable from minimum to the unit is a precision, long-life radial-piston
maximum as shown in pump chart pump controlled upon pressure demand by
the integral pressure switch. This switch is
• Quiet long life radial piston pump
adjustable, to give you precise and repeatable
• Filler breather with inlet screen clamping forces. The secondary pressure
• Leak free fittings and poppet valves is controlled by a poppet style pressure
reducing valve. This secondary low pressure
• Additional pressure gauges provided for circuit is adjustable between 450 and 5500
reduced pressure circuits
psi. Automatic pressure control is assured,
Multi-Pressure Pumps because the pump restarts if pressure drops.
Clamping pressure is assured even with an
electrical power failure since the solenoid
valves are mechanically held in the clamped
position - and only need power to unclamp.
The poppet design of these valves means
positive, leakage-free sealing.

Sample Circuit
CLR-877-EP

Adjustable Operating Pressure 1160-7250 psi 725-5075 psi 725-5075 psi
460 volts 230 volts 230 volts 115 volts 460 volts 230 volts
Power supply 3 Phase 3 Phase 1 Phase 1 Phase 3 Phase 3 Phase
60Hz 60Hz 60Hz 60Hz 60Hz 60Hz
Flow rate (cu.in./min.) 66 66 66 66 106 106
Usable fluid capacity (cu.in.) 400 400 400 400 400 400
Reservoir capacity (cu.in.) 690 690 690 690 690 690
Motor horsepower 1.5 1.5 1.0 1.0 1.5 1.5
Motor amperage 2.1 4.2 6.4 12.8 2.1 4.2
Nose level @ 3ft.(dBA) 75 75 75 75 75 75
Max. uninterrupted running time (sec.) 15-120 15-120 15-120 15-120 15-120 15-120
Max. % of cycle pump should operate 25-40% 25-40% 25-40% 25-40% 25-40% 25-40%
Two S/A Circuits, One Reduced W/One Pendent CLR-951-EP CLR-851-EP CLR-9521-EP CLR-8521-EP CLR-952-EP CLR-852-EP
Two D/A Circuits, One Reduced W/One Pendent CLR-953-EP CLR-853-EP CLR-9541-EP CLR-8541-EP CLR-954-EP CLR-854-EP
Two S/A Circuits, One Reduced W/Two Pendents CLR-955-EP CLR-855-EP CLR-9561-EP CLR-8561-EP CLR-956-EP CLR-856-EP
Two D/A Circuits, One Reduced W/Two Pendents CLR-957-EP CLR-857-EP CLR-9581-EP CLR-8581-EP CLR-958-EP CLR-858-EP
Two S/A Circuits, One Reduced W/One Pendent & Two CLR-959-EP CLR-859-EP CLR-9601-EP CLR-8601-EP CLR-960-EP CLR-860-EP
Pressure Switches
Two D/A Circuits, One Reduced W/One Pendent & Two CLR-971-EP CLR-871-EP CLR-9721-EP CLR-8721-EP CLR-972-EP CLR-872-EP
Pressure Switches
Two S/A Circuits, One Reduced W/Two Pendents & Two
CLR-973-EP CLR-873-EP CLR-9741-EP CLR-8741-EP CLR-974-EP CLR-874-EP
Pressure Switches
Two D/A Circuits, One Reduced W/Two Pendents & Two CLR-975-EP CLR-875-EP CLR-9761-EP CLR-8761-EP CLR-976-EP CLR-876-EP
Pressure Switches
Two S/A Circuits, One Reduced W/One Pendent, Two Pressure CLR-977-EP CLR-877-EP CLR-9781-EP CLR-8781-EP CLR-978-EP CLR-878-EP
Switches & One Pressure Relief Valve
Two D/A Circuits, One Reduced W/One Pendent, Two Pressure CLR-979-EP CLR-879-EP CLR-9801-EP CLR-8801-EP CLR-980-EP CLR-880-EP
Switches & One Pressure Relief Valve
Two S/A Circuits, One Reduced W/Two Pendents, Two Pressure CLR-981-EP CLR-881-EP CLR-9821-EP CLR-8821-EP CLR-982-EP CLR-882-EP 14
Switches & One Pressure Relief Valve
Two D/A Circuits, One Reduced W/Two Pendents, Two Pressure CLR-983-EP CLR-883-EP CLR-9841-EP CLR-8841-EP CLR-984-EP CLR-884-EP
Switches & One Pressure Relief Valve
