END MILLS

3412 Fantom 2.0 - Square End

5 Individually Designed Flutes
Eccentric Relief
Variable Index
Right Hand Spiral
Right Hand Cut
Dura Carb (Micrograin)
Speeds and Feeds, see fullertontool.com

Tolerance:
Shank Diameter: h6
Cutter Diameter: +.0000”” -.002”
+0.00mm -0.05mm

Tool EDP Number
Cutting Diameter Length Cutting Shank Overall Advanced
Length Diameter Length
Style FC 20 Performance
STB 3/8 1/4 2 37540
1/4 SD 3/4 1/4 2 1/2 37544
XL 1 1/4 1/4 3 37548
SD 7/8 5/16 2 1/2 37549
5/16 XL 1 5/16 3 37553
XL 2 5/16 4 37557
STB 1/2 3/8 2 1/2 37576
SD 1 3/8 2 1/2 37582
3/8
XL 1 1/4 3/8 3 37588
XL 2 3/8 4 37589
SD 1 7/16 2 3/4 37605
7/16
XL 2 7/16 4 37611
STB 5/8 1/2 3 37628
SD 1 1/2 3 37633
1/2 SD 1 1/4 1/2 3 37641
XL 1 5/8 1/2 4 37647
XL 2 1/2 4 37648
STB 3/4 5/8 3 1/2 37654
SD 1 1/2 5/8 3 1/2 37660
5/8 SD 1 5/8 5/8 4 37666
XL 2 1/4 5/8 5 37672
XL 3 1/4 5/8 6 37674
STB 7/8 3/4 4 37689
SD 1 1/4 3/4 4 37697 I M
SD 1 1/2 3/4 4 37704
3/4 IMPERIAL METRIC
SD 1 5/8 3/4 4 37713
XL 2 1/4 3/4 5 37715
XL 3 1/4 3/4 6 37717
SD 1 1/2 1 4 37739
1 SD 2 1 5 37747
XL 2 1/4 1 5 37748

■ Titanium ■ Super Alloys ■ Hardened Steels ■ Stainless Steels ■ Steels ■ Cast Iron ■ General Purpose

Visit fullertontool.com for the most up to date information. 55
