3412 Fantom 2.0 - Radius End

Cutting Diameter Cutting Shank Overall Reach Neck Corner EDP Number
Length Diameter Length Diameter Radius FC 20
5/8 1/2 6 3 3/8 .4800 .0300 37866
5/8 1/2 6 3 3/8 .4800 .0600 37868
1/2 5/8 1/2 6 4 1/8 .4800 .0600 37869
5/8 1/2 6 4 1/8 .4800 .0900 37871
5/8 1/2 6 4 1/8 .4800 .1200 37873
3/4 5/8 4 1 5/8 .6000 .0300 37874
5/8 3/4 5/8 6 2 3/8 .6000 .0300 37878
3/4 5/8 6 2 3/8 .6000 .0900 37884
1 3/4 4 2 .7200 .0300 37907
1 3/4 4 2 .7200 .0600 37908
1 3/4 4 2 .7200 .0900 37909
1 3/4 4 2 .7200 .1200 37910
1 3/4 4 2 .7200 .1900 37911
1 3/4 4 2 .7200 .2500 37912
1 3/4 6 2 1/2 .7200 .0300 37913
1 3/4 6 2 1/2 .7200 .0600 37916
1 3/4 6 2 1/2 .7200 .0900 37919
3/4 1 3/4 6 2 1/2 .7200 .1200 37922
1 3/4 6 2 1/2 .7200 .1900 37925
1 3/4 6 2 1/2 .7200 .2500 37928
1 3/4 6 3 3/8 .7200 .0300 37914
1 3/4 6 3 3/8 .7200 .1200 37923
1 3/4 6 4 1/8 .7200 .0300 37915
1 3/4 6 4 1/8 .7200 .0600 37918
1 3/4 6 4 1/8 .7200 .1200 37924
1 3/4 6 4 1/8 .7200 .1900 37927
1 1/4 3/4 4 2 1/2 .7200 .1200 37931
1 1/4 1 4 2 1/4 .9700 .0300 37973
1 1/4 1 4 2 1/4 .9700 .1900 37977
1 1/4 1 4 2 1/4 .9700 .2500 37978
1
1 1/4 1 6 2 5/8 .9700 .0300 37979
1 1/4 1 6 3 3/8 .9700 .0600 37983
1 1/4 1 6 4 1/8 .9700 .0600 37984
Metric
4.00 3.00 50.00 10.00 2.87 0.25 37758
3.00
4.00 3.00 50.00 12.00 2.87 0.25 37759
6.00 10.00 6.00 100.00 54.00 5.75 1.50 37790
8.00 27.00 8.00 76.00 35.00 7.75 1.00 37805
12.00 10.00 150.00 105.00 9.60 0.50 37833
10.00
20.00 10.00 100.00 54.00 9.60 0.50 37840
16.00 12.00 150.00 105.00 11.60 0.75 37850
12.00
20.00 12.00 100.00 54.00 11.60 0.50 37857
20.00 16.00 100.00 41.00 15.34 0.75 37890
16.00
20.00 16.00 150.00 89.00 15.34 0.50 37894
20.00 20.00 20.00 150.00 89.00 19.35 1.00 37932
32.00 25.00 100.00 57.00 24.00 0.75 37953
25.00
32.00 25.00 150.00 67.00 24.00 3.00 37967
