Page 668 - Deko-Light Light Impressions 2019-20
P. 668
FLEXIBLE LED-STRIPE
Dim. L x W x H: 5000 x 12 x 2 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 5 cables [4x V-, V+]
840153 A 1700 K 450 - 630 nm 300 LEDs 70 W 2700 lm / Stripe 540 lm / Meter EEI: A
24 SMD 120° 4 CH IP20 - 20°C M M
5050 + 40°C
Cutting option
over to 100 mm / 6 LED
FLEXIBLE LED-STRIPE
Dim. L x W x H: 3000 x 12 x 3 mm
LED rows: 2
Fixation: Adhesive tape rear side
Stripe connection: 5 cables [4x V-, V+]
840211 3000 K 450 - 630 nm 432 LEDs 30 W 1000 lm / Stripe 333 lm / Meter EEI: A
840212 6200 K 450 - 630 nm 432 LEDs 30 W 1000 lm / Stripe 333 lm / Meter EEI: A
12 SMD - 15°C M M
3528 120° 4 CH IP20 + 50°C
Cutting option
over to 85 mm / 12 LED
LED-STRIPES | 4 Channel 667
