Page 673 - Deko-Light Light Impressions 2019-20
P. 673
FLEXIBLE LED-STRIPE
Dim. L x W x H: 5000 x 15 x 5,5 mm
LED rows: 1
Fixation: Incl. mounting set
Stripe connection: 5 cables [4x V-, V+]
840145 2800 K 450 - 630 nm 480 LEDs 65 W 2350 lm / Stripe 470 lm / Meter EEI: A
24 SMD - 15°C M M
5050 120° 4 CH IP67 + 50°C
Cutting option
over to 83,3 mm / 8 LED
FLEXIBLE LED-STRIPE
Dim. L x W x H: 5000 x 15 x 4 mm
LED rows: 1
Fixation: Incl. mounting set
Stripe connection: 5 cables [4x V-, V+]
840218 4200 K 450 - 630 nm 480 LEDs 115 W 3400 lm / Stripe 680 lm / Meter EEI: A
840219 6200 K 450 - 630 nm 480 LEDs 115 W 3500 lm / Stripe 700 lm / Meter EEI: A
24 SMD 120° 4 CH IP67 - 15°C M M
5050 + 50°C
Cutting option
over to 83,3 mm / 8 LED
672 LED-STRIPES | 4 Channel
