Page 672 - Deko-Light Light Impressions 2019-20
P. 672
FLEXIBLE LED-STRIPE
Dim. L x W x H: 5000 x 12 x 4,5 mm
LED rows: 1
Fixation: Incl. mounting set
Stripe connection: 5 cables [4x V-, V+]
840240 4200 K 450 - 630 nm 300 LEDs 70 W 2600 lm / Stripe 520 lm / Meter EEI: A
840241 6200 K 450 - 630 nm 300 LEDs 65 W 2800 lm / Stripe 560 lm / Meter EEI: A
24 SMD 120° 4 CH IP67 - 15°C M M
5050 + 50°C
Cutting option
over to 100 mm / 6 LED
FLEXIBLE LED-STRIPE
Dim. L x W x H: 5000 x 12 x 4,5 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 5 cables [4x V-, V+]
840239 3000 K 450 - 630 nm 300 LEDs 65 W 2600 lm / Stripe 520 lm / Meter EEI: A
24 SMD - 15°C
5050 120° 4 CH IP67 + 50°C
Cutting option
over to 100 mm / 6 LED
LED-STRIPES | 4 Channel 671
