Page 669 - Deko-Light Light Impressions 2019-20
P. 669
FLEXIBLE LED-STRIPE
Dim. L x W x H: 5000 x 12 x 3 mm
LED rows: 2
Fixation: Adhesive tape rear side
Stripe connection: 5 cables [4x V-, V+]
840104 3000 K 450 - 630 nm 720 LEDs 38 W 1400 lm / Stripe 280 lm / Meter EEI: A
840102 6500 K 450 - 630 nm 720 LEDs 38 W 1400 lm / Stripe 280 lm / Meter EEI: A
12 SMD 120° 4 CH IP20 - 15°C M M
3528 + 50°C
Cutting option
over to 85 mm / 12 LED
FLEXIBLE LED-STRIPE
Dim. L x W x H: 3000 x 12 x 3 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 5 cables [4x V-, V+]
840213 3000 K 450 - 630 nm 288 LEDs 80 W 2400 lm / Stripe 800 lm / Meter EEI: A
840214 4200 K 450 - 630 nm 288 LEDs 80 W 2400 lm / Stripe 800 lm / Meter EEI: A
840215 6200 K 450 - 630 nm 288 LEDs 80 W 2400 lm / Stripe 800 lm / Meter EEI: A
24 SMD - 15°C M M
5050 120° Ra>90 4 CH IP20 + 50°C
Cutting option
over to 83,3 mm / 8 LED
668 LED-STRIPES | 4 Channel
