Page 671 - Deko-Light Light Impressions 2019-20
P. 671
FLEXIBLE LED-STRIPE
Dim. L x W x H: 3000 x 19 x 2 mm
LED rows: 2
Fixation: Adhesive tape rear side
Stripe connection: 5 cables [4x V-, V+]
840061 6000 K 450 - 630 nm 360 LEDs 75 W 3800 lm / Stripe 1266 lm / Meter EEI: A
24 SMD - 15°C M M
5050 120° 4 CH IP20 + 50°C
Cutting option
over to 100 mm / 12 LED
FLEXIBLE LED-STRIPE
Dim. L x W x H: 5000 x 14 x 4 mm
LED rows: 2
Fixation: Incl. mounting set
Stripe connection: 5 cables [4x V-, V+]
840052 3000 K 450 - 630 nm 720 LEDs 36 W 1000 lm / Stripe 200 lm / Meter EEI: A
12 SMD - 15°C M M
3528 120° 4 CH IP65 + 50°C
Cutting option
over to 85 mm / 12 LED
670 LED-STRIPES | 4 Channel
