Page 824 - Deko-light Catalogue 2022
P. 824
width in mm voltage [DC] W / m type light colour colour temperature lm / m LED / m length in mm protection class item number page
10,0 24V 16,5 COB 660 840 5000 IP20 840375 831
10,0 24V 16,0 Standard 4000K 765 60 5000 IP44 840373 859
10,0 24V 16,5 Standard 6500K 840 60 5000 IP44 840357 859
10,0 48V 19,0 Standard 4000K 1755 700 5000 IP20 840346 843
10,0 48V 19,0 Standard 3000K 1645 700 5000 IP20 840344 843
10,0 24V 18,5 Standard 2700K 1215 240 5000 IP20 840192 839
10,0 24V 19,0 Standard 3000K 1605 240 5000 IP20 840193 839
10,0 24V 19,0 Standard 3000K 1605 240 50000 IP20 930514 839
10,0 24V 20,0 Standard 4000K 1770 240 5000 IP20 840194 839
10,0 24V 20,0 Standard 4000K 1770 240 50000 IP20 930515 839
10,0 24V 19,0 Standard 3000K 1625 120 5000 IP20 840325 839
10,0 24V 19,0 Standard 3000K 1740 120 50000 IP20 840335 839
10,0 24V 19,0 Standard 4000K 1560 120 5000 IP20 840326 839
10,0 24V 19,5 Standard 4000K 1560 120 50000 IP20 840336 839
10,0 24V 20,0 Standard 6000K 1720 120 5000 IP20 840124 840
10,0 24V 21,0 Standard 3000K 1595 120 5000 IP20 840122 840
10,0 24V 22,5 Standard 3000K 2520 160 5000 IP44 840333 841
10,0 24V 22,5 Standard 4000K 2555 160 5000 IP44 840334 841
10,0 24V 22,5 Standard 2700-6500K 1765 120 5000 IP20 840348 849
10,0 24V 22,5 Standard 4000K 2815 160 5000 IP20 840332 840
10,0 24V 22,5 Standard 3000K 2570 160 5000 IP20 840331 840
10,0 24V 23,5 Standard 2700-6500K 1565 120 5000 IP44 840347 850
10,5 12V 7,0 Standard 2700K 550 120 5000 IP67 840172 834
10,5 24V 11,5 Standard 2700K 900 180 5000 IP67 840186 841
10,5 24V 11,0 Standard 3000K 930 180 5000 IP67 840187 841
12,0 24V 10,5 D FLEX Side View 3000K 368 144 5000 IP68 840287 877
12,0 24V 10,5 D FLEX Side View 3200K 210 84 5000 IP68 840290 881
quick finder sorted in ascending order by width and performance
822 LED STRIPES | quick finder
