P. 962
DEKO-LIGHT R-DMX 3+1
RDM means »Remote Device Management«. This remote
device management enables the control of the RDMX 3+1
from the control panel. This provides a great advantage,
specifically for inaccessible installations or sites that are
difficult to reach. If RDM is not available, the DMX address
assignment can also be set manually via the DIP switch.
complies with the DMX 512/1990, RDM protocol/2009
supports automatic DMX addressing
incl. top-hat rail adapter
incl. 2m CAT5 cable [RJ45]
flicker free
connection: terminals
dimensions L x W x H: 120 x 43 x 23 mm
max. 4A each channel
power: 4x 48W [192W] at 12V,
4x 96W [384W] at 24V
843273 black 79,95 €
12-24 CV CAT 3 / 4
5
DEKO-LIGHT 4 CHANNEL LED DMX DIMMER 12-48V
simple and powerful 4 channel dimmer
RDM capable with compatible controllers
[remote configuration, e.g. DMX address]
use in conjunction with DMX wall controller
or DMX512 PC software
flicker free
connection DMX in/out: CAT5 or terminal
connection DC in/out: terminal
dimensions L x W x H: 140 x 50 x 26 mm
max. 4A each channel
power: 4x 48W [192W] at 12V,
4x 96W [384W] at 24V,
4x 192W [768W] at 48V
843060 black 89,95 € new
12-48 CV 4
960 CONTROLLER | DMX dimmer
