P. 488

454                       Applied  Process  Design for Chemical  and Petrochemical  Plants

            Code Requirements for External Fire  Conditions         7. To  provide  some  external  protection  against  the
                                                                      damage  that  an  external  fire  can  do  to  a  pressure
              Paragraph UG-125  (3)  of the ASME code  [I]  requires   relief valve or rupture disk,  this author recommends
            that  supplemental  relieving  capacity  be  available  for  an   that these  devices  be  insulated  after installation  in
            unfired  pressure vessel  subject to external  accidental fire   such a  manner as  not to restrict their action but to
            or other unexpected  source  of heat.  For this  condition,   provide  some  measure  of  reliable  performance,
            relieving devices must be installed to prevent the pressure   even if the vessel is not insulated.
            from  rising  more  than  21 %  [13]  above  the  maximum
            allowable working pressure of the vessel. The set pressure   Pressure Relief Valve Orifice Areas on Vessels  Containing Only
            should not exceed the vessel l\'IAWP.  A single relief device   Gas,  Unioetted Surf  ace
            may  be  used  for this  capacity  as  long as it also meets  the
            normal  overpressure  design  for other  possible  causes  of
            10 percent.  If desirable,  multiple separate  devices  can be   Due to gas expansion from external fire, the API code
            installed to satisfy both  potential overpressure situations.   [I  0]  provides  for calculation  of the  pressure  relief valve
              For this  condition,  the API-RP-521  Code  [13]  (Figure   orifice area for a gas containing vessel exposed to external
            7-7A)  shows  an  allowable  16%  maximum  accumulation   fire on the unwetted surface:
            relieving pressure above the set pressure. For external fire
            conditions  on a vessel,  the  maximum allowable  accumu-
            lation  pressure  is  21 %  above  the  set  pressure  [13]  for                                  (7- 32)
            both single or multiple relieving devices  (Figure 7-7  A).
                                                                    Based on  air and  perfect gas  laws, vessel  uninsulated,
            Design Procedure                                      and vessel  will  not reach rupture  conditions.  Review  for
                                                                  specific design situations  [33a]
              The  usual  procedure  for  determining  relief  area
            requirements is:
                                                                 where  A  = effective discharge area of valve,  sq in.
              l. Determine the external surface area exposed to fire,
                as set forth  by                                       F' = operating environment factor,  min value recom-
                                                                           mended = 0.01  when the minimum value is
                 Q =  21,000 FAw+o.s 2                   ( 7-30)           unknown, use F'  = 0.045. Can be calculated by  [33c]
                                                                                 [          25   :
                 and  Table  7-8  and  the  paragraph  on  Surface  Area   F'  =  0.1406   (Tw  - T  1) 1.    (7 - 33)
                                                                                      .
                 Exposed to Fire.                                           CK  d    1 1  o.6506
              2. Determine the heat absorbed, Q, from Figure 7-30.     A 3  = exposed surface area of  vessel,  sq ft
              3. Calculate the rate of  vaporization of liquid from    P 1  =  upstream relieving pressure,  psiabs.  This is the set
                                                                           pressure plus the allowable overpressure plus the
                                                                           atmospheric pressure, psiabs.
                                                         (7 - 31)
                                                                  where  M  = Molecular weight of  gas/vapor.
              4.  Verify  critical  pressure from Equation  7-7 and estab-
                lish actual back pressure for relieving device.        A3  =  exposed surface area of the vessel,  in square feet.
              5.  Calculate  relieving  area  by  applicable  equation  for   P 1  =  upsu-earn relieving pressure,  in pounds per square
                 critical or non-critical flow,  using the flow rate deter-   inch absolute. This is the set pressure plus the allow-
                 mined  in  (3)  above.  (See  Equation  7-10 and follow-   able overpressure plus the atmospheric pressure.
                 ing). The area  actually  selected for orifice  of safety   C  =  coefficient determined by  the ratio of the specific
                 type valve must have orifice equal  to or greater than    heats of the gas at standard conditions.  This can be
                 calculated requirements.  For a rupture disk  applica-    obtained from  Equation  2  [33a]  in 4.3.2.1  of  API
                 tion,  the full  free  open cross-sectional  area  of pipe   Recommended Practice 520,  Pan I,  or Figure 7-25.
                 connect.ions in inlet and  exit sides must be equal  to   K.:i  = coefficient of discharge  (obtainable from the valve
                 or be greater than  the calculated area.                  manufacturer). K.:i  is  equal  to 0.975 for sizing relief
              6.  Select a valve  or rupture  disk  to  accommodate  the   valves.
                 service application.                                  Tw  = vessel wall  temperature,  in  degrees Rankine.
