Applied Process Design 491

(text continued from page 186) tion, effects of temperature and pressure are valid only
v1, v2, etc. = volume percent of each combus- for enclosed conditions, such as tanks, vessels, piping and
tionable gas present in mixture, other processing equipment. See Figures 7-49A and 7-49B
free from air and inert gas and Table 7-22 for LEL or UEL showing a variation of lim-
its with temperatures and pressures.
(7-55)
Extreme care must be exercised in designing poten-
tially flammable systems to use reliable flammability limits
L 1, � . L3 •.. = lower flammability limits, vol% for each flam- data and to recognize the effects of pressure/temperature
mable gas in mixture
on the data and its implications to the safety of the system
in question. Unless otherwise indicated, most published
Example 7-13: Calculation of LEL for Flammable Mixture
data is at atmospheric pressure and ambient temperature
and should be corrected for other conditions.
Assume mixture analysis ( combustible with air):
Methane, 3.0%, LEL = 5.3% Figure 7-4 7 illustrates a gas-freeing system using gaso-
Propane, 4.0%, LEL = 2.3% line-air-water-vapor (the water vapor could be steam). The
Hexane, LQ%, LEL = 1.1% mixture "A" represents a saturated gasoline-vapor-air-
Subtotal 8.0% combustible water-vapor mixture at 70°F. In a closed tank, a more
Balance is air (92%) volatile gasoline than the one diagrammed would give a
saturated mixture with gasoline vapor and less air. A less
For each component: v, combustible only on air-free basis. volatile gasoline would give less gasoline vapor and more
Methane.X (100) = 37.5% air. If a continuous supply of air saturated with water
Propane.X (100) = 50.0% vapor is added to a tank containing mixture A, all com-
Hexane.X (100) = 12.5% positions between A and B (air plus water vapor) will be
Percentage combustible only = 100.0% formed until all the gasoline vapor has been flushed from
the tank and only steam remains (at 212°F or higher). If
100
Mixture composite LEL = -----------=--.:..:;_ _ the tank is cooled, the steam will condense and air will be
37.::i/::i.3 + 50/2.3 + 12.5/ 1.1 drawn into the tank giving mixtures along CrB. At 70°F
only air plus a small amount of water vapor will remain.
= 2.48% volume for mixture If hot water and water vapor at l 75°F are used to flush
mixture A from the tank, the mixture composition can
The UEL for a composite is determined in the same man- only shift along AC to E. Mixtures between A and E are
ner, using the respective component UEL values. For the
overall mixture, the above can be used to calculate the flushed from the tank, mixed with air to give a mixture
between parts AE and B. After examining several other
composition. Also see Ref [52].

,. olr • 100 ,. _ ,. combu1tlble vopcr - ,. inert
Pressure and Temperature Effects

The temperature and pressure of a liquid system are
important in determining the effects created that result
in a fire and explosion hazard. Because this relates to the
flash point and flammability limits, see Tables 7-21, 7-22
and Figures 7-48, and 7-49A, and 7-49B [34). Flammable
mhltur11
• An increase in pressure raises the flash point, while a
decrease lowers the flash point [39, 34].
• As temperature is increased on a liquid, its vapor
pressure will increase and will therefore tend to
vaporize at a greater rate [34].

In a closed container, equilibrium develops at any INERT, volume- percent -
given temperature and pressure, while in an open condi-
tion (not enclosed) the liquid will continue to vaporize in Figure 7-48. Effect of initial temperature on limits of flammability of
a combustible vapor-inert-air system at atmospheric pressure. By
air until the liquid is completely vaporized. In that situa- permission, U.S. Bureau of Mines, Bulletin 627 [43].
