Page 93 - Repower Reference Guide (2020) 8M0149179

PROPELLERS FOR PLUS SERIES ENGINES

Diameter (inches) Pitch (inches) Blades Material Approx. Gross Boat Wgt. (lbs.) Approx. Boat Length (ft.) Speed Range (mph)
13.50 28 3 Stainless Steel 8000-9200 27-30 58-64

496 HO -BRAVO ONE AND THREE

Plus Series ‑ 496 HO Bravo ‑ (425 HP) ‑ V8 Bravo One X
Quicksilver Propellers ‑ For Single Engine Boats
WOT: 4600‑5000 RPM, Standard Gear Ratio 1.50:1
High Altitude (5,000+ ft.) Gear Ratio: 1.65:1
Right Hand Rotation Standard
Diameter (inches) Pitch (inches) Blades Material Approx. Gross Boat Wgt. (lbs.) Approx. Boat Length (ft.) Speed Range (mph)
15.75 15 3 Stainless Steel 7500-9800 27-30' 34-43
15.5 17 3 Stainless Steel 6500-7800 26-28' 41-49
15.25 19 3 Stainless Steel 5700-6700 25-27' 47-55
14.75 21 3 Stainless Steel 5100-5900 24-26' 53-61
14.63 23 3 Stainless Steel 4600-5300 Up to 25' 59-66
MERCRUISER Plus Series ‑ 496 HO Bravo ‑ (425 HP) ‑ V8 Bravo One X
Quicksilver Propellers ‑ For Twin Engine Boats
WOT: 4800‑5200 RPM, Standard Gear Ratio 1.50:1
High Altitude (5,000+ ft.) Gear Ratio: 1.65:1
Right & Left Hand Rotation Required for Twins

Diameter (inches) Pitch (inches) Blades Material Approx. Gross Boat Wgt. (lbs.) Approx. Boat Length (ft.) Speed Range (mph)
15.75 15 3 Stainless Steel 14400-18900 32-36' 34-43
15.5 17 3 Stainless Steel 12100-14800 31-33' 41-49
15.25 19 3 Stainless Steel 10400-12400 30-32' 47-55
14.75 21 3 Stainless Steel 9000-10600 28-31' 53-61
14.63 23 3 Stainless Steel 7900-9200 Up to 29' 59-66
Plus Series ‑ 496 HO Bravo ‑ (425 HP) ‑ V8 Bravo Three X
Propellers ‑ For Single Engine Boats
WOT: 4600‑5000 RPM, Standard Gear Ratio 1.81:1
High Altitude (5,000+ ft.) Gear Ratio: 2.00:1

Diameter (inches) Pitch (inches) Blades Material Approx. Gross Boat Wgt. (lbs.) Approx. Boat Length (ft.) Speed Range (mph)
16.00 20 4 Stainless Steel 6800-8100 26-30' 40-47
14.38 20 3 Stainless Steel 6800-8100 26-30' 40-47
15.75 22 4 Stainless Steel 6100-7100 25-27' 45-52
14.25 22 3 Stainless Steel 6100-7100 25-27' 45-52
15.50 24 4 Stainless Steel 5500-6300 24-26' 50-57
14.25 24 3 Stainless Steel 5500-6300 24-26' 50-57
15.25 26 4 Stainless Steel 5000-5700 24-25' 55-62
14.00 26 3 Stainless Steel 5000-5700 24-25' 55-62
15.00 28 4 Stainless Steel 4600-5200 Up to 25' 60-67
13.75 28 3 Stainless Steel 4600-5200 Up to 25' 60-67

76
