SMARTCRAFT RIGGING

TRIM TAB INTERFACE KIT
STEERING ANGLE SENSORS
STEERING/SPEEDO SENSOR KIT SMARTCRAFT RIGGING

8M0100069 218.48
Shows digital K‑Plane trim on SmartCraft Instrumentation
For use with digital K‑Planes and SmartCraft Instrumentation 863188A 3 146.74
Mercury Branded
Provides steering angle and degrees, and speed to SmartCraft instruments
so gauge can display steering position and speed ‑ useful when docking.
ADD-ON SENSOR HARNESSES - MCM Includes steering/speedo‑pitot harness P/N 84‑863736, required for newer
engines that do not have the steering/speedo‑pitot harness included with engine
harness.
PADDLE WHEEL HARNESS Fits all SmartCraft compatible MerCruiser and Mercury Racing products.
STEERING SENSOR KIT

84-864553T 11.36
Harness connects paddle wheel to SmartCraft system.
Fits non‑DTS smallblock and V‑6 MerCruiser engines prior to serial 863188T 4 94.92
0W600000. Provides steering angle and degrees to SmartCraft instruments so gauge
can display steering position ‑ useful when docking.
TRANSOM HARNESS Fits all SmartCraft compatible MerCruiser and Mercury Racing products.
STEERING SENSOR KIT

84-863931A 1 9.82
Used to connect Steering/Speedo Sensor Kit 863188A 3 to MCM 4.3L,
5.0L, 5.7L (350Mag) and 6.2L MPI sterndrive engines. 863188A 5 122.41
Fits non‑DTS smallblock and V‑6 MerCruiser engines prior to serial Provides steering angle and degrees to SmartCraft instruments so gauge
0W600000. can display steering position ‑ useful when docking. Includes steering
harness 84‑864219 & 84‑863931
3-PIN TANK HARNESS Fits all SmartCraft compatible MerCruiser and Mercury Racing product . Also used
on CMD engines

84-864218 13.02
Fits older MCM/MIE mechanical engines that are equipped with a 3‑pin
tank harness connector.
