ELECTRICAL

84-8M0131382 ADAPTER HARNESSES - 14 PIN
Data harness built for long run installations (10 gage wire ‑ internal power/
wake) 80 ft. Provides data link between DTS engine and command
module harness. DUAL HELM ADAPTER KIT- DTS
All 2005 and newer DTS engines (Verado/OptiMax/MCM)
84-8M0131383
Data harness built for long run installations (10 gage wire ‑ internal power/
wake) 90 ft. Provides data link between DTS engine and command
module harness.
All 2005 and newer DTS engines (Verado/OptiMax/MCM)
84-8M0131384
Data harness built for long run installations (10 gage wire ‑ internal power/
wake) 100 ft. Provides data link between DTS engine and command
module harness.
All 2005 and newer DTS engines (Verado/OptiMax/MCM)
84-8M0131385
Data harness built for long run installations (10 gage wire ‑ internal power/ 84-893330K01 75.50
wake) 110 ft. Provides data link between DTS engine and command Used with dual stations/ dual helms ‑ Requires one for single‑engine
module harness. installation and two for dual‑engine installation. Adapts primary 14‑pin
All 2005 and newer DTS engines (Verado/OptiMax/MCM) data harness to dual helms.
84-8M0131386
Data harness built for long run installations (10 gage wire ‑ internal power/ ELECTRICAL
wake) 120 ft. Provides data link between DTS engine and command
module harness. SC HARNESS ASSEMBLY- POWER HARNESS-HELM
All 2005 and newer DTS engines (Verado/OptiMax/MCM)
ELECTRICAL 14 PIN FEMALE WEATHER CAP

84-888416T08 15.15
10 ft. harness. Used to reduce voltage drop when battery is located near
the helm of the boat. Connects to junction box at the helm.
8M0126960 7.68
Heavy Duty 14 pin Female Weather Cap Used on all DTS engines. 18.20
84-888416T07
Reusable weather cap to be used to protect the integrity of the 14 pin data cable
when connections are not able to be immediately made 14 ft. harness. Used to reduce voltage drop when battery is located near
the helm of the boat. Connects to junction box at the helm.
14 PIN MALE WEATHER CAP Used on all DTS engines.
HARNESS- 25 FT CLEAN POWER

8M0126959 7.68
Heavy Duty 14 pin Male Weather Cap
Reusable weather cap to be used to protect the integrity of the 14 pin data cable 84-896333T25 29.32
when connections are not able to be immediately made 25 ft. harness. Used to reduce voltage drop when battery is located near
the helm of the boat. Connects to junction box at the helm.
Used on all DTS Engines
