MECHANICAL REMOTE CONTROLS

SIDE MOUNT REMOTE CONTROL- 8 PIN TRADITIONAL MSC 4000 SIDE MOUNT - ELECTRIC NON-POWER
TRIM

SIDE MOUNT REMOTE CONTROL- 14 PIN

8M0176295 255.22
This control features a handle mounted power trim switch, 20 ft. (6.1 m) harness,
built‑in warning horn and includes power trim leads for front mount switch.
Fits all current Mercury/Mariner outboards (with integral power trim) and 1993 and
newer Force outboards 40 HP and higher utilizing Mercury style cables (with power 237.83
trim). When used with MY2005 and newer 8/9.9, 15/20 FourStroke outboards an 8M0176289
adapter harness is required. This control features non ‑ power trim and a 15ft. (4.58m) harness with 14 pin
For MY2005 and newer 8/9.9 FourStroke outboards SAE T/S cables must be used. Deutsch connector.
GEN II cables must be used. Fits all current Mercury/Mariner Outboards 6 HP and above (without power trim),
and 1993 and newer Force Outboards 40 HP and higher utilizing Mercury cables
SIDE MOUNT REMOTE CONTROL- 8 PIN AMP (without power trim).
8M0103449 250.04 When used with a MY2005 and newer 8/9.9, 15/20 FourStroke Outboard an
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov Adapter harness is required. 2 pin connector is now included to allow for use of
SmartCraft accessories with analog gauges.
This control features a handle mounted power trim switch, 15 ft. (4.58 m) Gen II cable must be used.
harness with Amp 8‑pin connector. The control will connect to the engine
models below without the use of an adapter. SIDE MOUNT REMOTE CONTROL
Used on MY2005 and newer, 8/9.9, 15/20 FourStroke engines with electric start
and power trim.
For 8/9.9 FourStroke engines generation change above S/N OR192772 and 15/20
FourStroke engines will use GEN I cables.
GEN II cables must be used on other engines.
SIDE MOUNT REMOTE CONTROL

8M0176291 255.22
This control features a handle mounted power trim switch, 20 ft. (6.1 m) harness
with Amp 10‑pin connector. The control will connect to the engine models below 881170A 5 249.05
without the use of an adapter harness. WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Used on MY2005 and newer, 8/9.9, 15/20 FourStroke engines with electric start
and power trim. For 8/9.9 FourStroke engines generation change above S/N This control features a non ‑ powered trim handle with a 15 ft.(4.58 m)
harness. This control does not have a warning horn and features push
OR192772 and 15/20 FourStroke engines will use GEN I cables. GEN II cables
must be used on other engines. throttle cable operation.
Fits Mercury/Mariner Outboards 20/25 HP (U.S. S/N 0G044026 and below;
SIDE MOUNT REMOTE CONTROL Belgium S/N 9807908 and below).
GEN I cables must be used.
SIDE MOUNT REMOTE CONTROL

8M0176297 256.14
This control features a handle mounted power trim switch, 15 ft. (4.58 m) harness
with push to choke 14‑pin connector. Push to choke key may require additional 236.82
engine adapter. 8M0103454
Fits all current Mercury/Mariner outboards 6 HP and above and 1993 and newer WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Force outboards 40 HP and above (with power trim). This control features a non‑power trim handle, 15 ft.(4.58 m) harness and
GEN II cables must be used. built‑in warning horn.
Fits all current Mercury/Mariner Outboards 6 HP and above (without power
trim) and 1993 and newer Force Outboards 40 HP and higher utilizing Mercury
style cables (with power trim).
For MY2005 and newer 8/9.9 FourStroke Outboards SAE T/S cables must be
used. MECHANICAL REMOTE CONTROLS
For 8/9.9 FourStroke engines generation change above S/N OR192772 and 15/20
FourStroke engines will use GEN I cables.
When used with a MY2005 and newer 8/9.9, 15/20 FourStroke Outboard an
Adapter harness is required.
GEN II cables must be used on other engines.
