ELECTRICAL

POWER TRIM EXTENSION HARNESS
OPTIONAL REMOTE CONTROL HARNESSES
REMOTE CONTROL HARNESS

84-865772T02
24 ft.(4.88 m) harness.
This harness connects the remote control 4 pin Molex connector to the newer
design 3 pin Packard pump trim pump connector. 84-819200T 1
MCM/MIE 15‑1/2 ft.(4.7 m) ten‑wire cable for large boats when standard remote control cable
is too short.
POWER TRIM ADAPTER HARNESS Fits Force (1992 and prior) outboards with 10‑wire engine harnesses.
LANYARD STOP SWITCHES

Lanyard cord attaches to the toggle switch or cap and boat driver. When
switch toggles or cap pulls off switch, the ignition is interrupted and the
engine shuts down.

LANYARD STOP SWITCH

84-865770A02
12 in.(305 mm) harness.
To convert older P/T pump with 3 blade connector to newer remote control harness
with 3 pin Packard connector.
POWER TRIM ADAPTER HARNESS

87- 19674A05
5 ft.(1.53 m) harness. Surface mount or flush mount. Used when mounting
controls with no lanyard switch included
QUICKSILVER® RIGGING 12 in.(305 mm) harness. LANYARD STOP SWITCH
MCM/MIE engines. Do not use on DTS engines

84-865771A02
To convert newer P/T pump with 3 pin Packard connector to older remote control
harness with 3 blade connector.

87- 19674A06
5 ft.(1.53 m) harness. 2 inch cut out with Black bezel. Used when mounting
controls with no lanyard switch included.
Chrome bezel optional ‑ order separate.
MCM/MIE engines. Do not use on DTS engines
