STEERING

FITTING-TEE BLEEDER
QUICKSILVER STEERING WHEELS
STEERING WHEEL

22-8M0041173
3/8 Comp x 6 ORFS
Tee fitting used on the compression style cylinders (1500 PSI)
8M0050097 and 8M0054993 cylinders 67-829140A01
Legend Steering Wheel with soft grip and wheel center This product is a
FITTING BULKHEAD 3 INCH four‑spoke wheel design.
Wheel Dia.: 13‑1/2 inch
Dish: 3‑7/8 inch
TELEFLEX NON-NFB SAFE-T QC ROTARY
STEERING SYSTEMS

Designed with standard 3/4 in.(19 mm) round taper steering shaft and
stainless steel cable output ends for maximum corrosion resistance.
Features cable with quick connect to steering helm. Three turns
lock‑to‑lock for standard travel. 90 degree helm mount.
22-8M0055326 SAFE-T QUICK CONNECT STEERING SYSTEM
Bulkhead fitting used with compression style steering hoses (.375 inch
compression X 3 inch LG)
Hydraulic Compression Steering Systems
FITTING - TEE

QUICKSILVER® RIGGING Used with Compression style hydraulic systems. 10 ft. (3.0m)
64-826472A10

64-826472A11
11 ft. (3.4m)
22-8M6001390
64-826472A12
12 ft. (3.7m)
Tee ‑ 3/8 in. Compression X 3/8 in. male
64-826472A13
Hydraulic Compression style systems ‑ Basic and Heavy Duty
FITTING - 90 DEGREE 13 ft. (4.0m)
64-826472A14
14 ft. (4.3m)
64-826472A15
15 ft. (4.6m)
64-826472A16
16 ft. (4.9m)
64-826472A17
17 ft. (5.2m)
64-826472A18
18 ft. (5.5m)
64-826472A19
22-8M6001392 19 ft. (5.87m)
Used with Compression style hydraulic systems.
90 degree‑ 3/8 in. Compression X 3/8 in.male
Hydraulic Compression style systems ‑ Basic and Heavy Duty
