STEERING

Brand Year Range Model Front Pivot STERNDRIVE ADD-A-STATION/AUTOPILOT KIT
Mount O/B
Cylinder
Yamaha 1990 - 2019 250 HP 64-804378A 1
Yamaha 1998 - 2019 40-50-60 HP 64-804378A 1
Yamaha 1998 - 2019 70and 90 HP 64-804378A 1
Yamaha 1994 - 2019 80,100 HP 4- 64-804378A 1
Stroke

TELEFLEX NFB SEASTAR REPLACEMENT PARTS
HELM VENTED FILL PLUG 64-826496A 1
Contains fittings for adding either a steering station or an autopilot system to an
existing SeaStar stern drive steering system. Allows use of SeaStar nylon tubing
(with SeaStar 1.7 helms only). Includes non‑vented fill plug for helm at lower most
station.
CYLINDER SEAL KIT

64-826523
Comes with every SeaStar helm. Must be used in all single steering station
systems or on the uppermost helm in multiple steering stations.
HELM NON-VENTED FILL PLUG
64-826532A 1
Replacement front seal for kit for SeaStar front mount cylinders (HC5340/HC5342/
HC5365). Includes 2 seal glands, pin wrench and guide tool.
BOTTLE FILLER KIT

64-826524
For use on lower station in multi‑station systems only. Included with kit
64‑826495A 1 (HK5501)
OUTBOARD ADD-A-STATION/AUTOPILOT KIT
64-826525A 1 QUICKSILVER® RIGGING
For filling and bleeding of the hydraulic system.
TELEFLEX NFB SEASTAR TIE BAR KITS

TIE BAR KIT

64-826495A 1
Contains fittings for adding either a steering station or an autopilot system to an
existing SeaStar outboard steering system. Includes 25 ft.(7.3 m) of SeaStar 3/8 in.
(9.5 mm) diameter nylon tubing and non‑vented fill plug for helm at lower most
station.

64-826507A 2
Includes the adapter plates, tie bar and hardware required to connect twin engines
utilizing single or twin front mount outboard cylinder(s) p/n 64‑826491A 1(HC5342).
Fits Mercury/Mariner V‑6 135‑200 HP (1989), 75‑250 HP (1990), 75‑275 HP (1991
and newer) and Hi‑Perf 2.4/2.5L EFI (1995 and newer).
