STEERING

HOSE CONNECTION KIT
TELEFLEX NFB SEASTAR PRO HYDRAULIC O/B
STEERING

The most popular outboard hydraulic steering system offering smooth,
super‑efficient No FeedBack Steering designed for today's high
performance hulls with single or multiple outboards up to 600 HP
combined. SeaStar Pro Steering systems are totally self‑contained,
non‑power‑assisted units that make steering a boat a truly enjoyable
experience. Their super‑efficient hydraulic operations produces an
effect most people equate with "power steering". Although some dash
modifications are required when you upgrade from a mechanical
system, there are no pressure vessels or powers units to mount. 4.0
64-826498A 1 turns lock‑to‑lock. SeaStar Pro is suitable for use with jack plates and
Connects 3/8 in.(9.5mm) diameter copper tubing to SeaStar Cylinders (using performance props. Packaged complete with helm, cylinder, fittings, oil,
SeaStar Outboard Hoses) bleeder kit and detailed instruction sheet.
FRONT PIVOT MOUNT CYLINDER CHART SEASTAR PRO HELM

Front Pivot Mount Outboard Cylinder
See Teleflex application guide for additional Information
Brand Year Range Model Front Pivot
Mount O/B
Cylinder
Honda 1996 - 2019 75-90 HP 64-804378A 1
Honda 1998 - 2019 30-50 HP 64-804378A 1
Johnson/Evinrude 1997 - 2019 65-175 HP 64-804378A 1
Johnson/Evinrude 1991 - 2019 200-225 HP 64-804378A 1 64-851625A 1
Johnson/Evinrude 1991 - 2019 250-300 HP 64-804378A 1 SEASTAR PRO TILT HELM
Johnson/Evinrude 1996 - 2019 90-225 HP Ficht 64-804378A 1
Johnson/Evinrude 1998 - 2019 65-70 HP 4-Stroke 64-804378A 1
Mercury/Mariner 1984 - 1994 2.4/2,5 EFI 64-804378A 1
Mercury/Mariner 1989 - 2019 75-300 HP 64-804378A 1
Mercury/Mariner 1998 - 2019 30-60 HP 64-804378A 1
Mercury 2002 - 2019 225 EFI 64-889457A01
FourStroke
Nissan/Tohatsu 1990 - 2019 90-140 HP 64-804378A 1
Suzuki 1986 - 2019 100 HP 64-804378A 1
Suzuki 1986 - 2019 115-140 HP 64-804378A 1
64-853690A 1
Suzuki 1986 - 2019 150-225 HP 64-804378A 1
Suzuki 1998 - 2019 65-70 HP 4-Stroke 64-804378A 1 SEASTAR HELM MOUNT QUICKSILVER® RIGGING
U S Marine/Force 1996 - 2019 90-120 HP 64-804378A 1
Yamaha 1997 - 2019 100-225 HP 64-804378A 1
Yamaha 1987 - 2019 225HP 64-804378A 1
Yamaha 1990 - 2019 250 HP 64-804378A 1
Yamaha 1998 - 2019 40-50-60 HP 64-804378A 1
Yamaha 1998 - 2019 70and 90 HP 64-804378A 1
Yamaha 1994 - 2019 80,100 HP 4- 64-804378A 1
Stroke

64-826484
This kit is designed to mount a SeaStar and SeaStar Pro helm at a 20 degree
angle to the mounting surface. Four possible mountings by varying wedge position.
No helm modifications are required.
