STEERING

DUAL ENGINE TIE BAR
RIDEGUIDE ATTACHING KITS
Through tilt tube type. When converting tiller handle steering to remote
steering, the existing co‑pilot friction control should be disabled or
removed.

STEERING LINK ROD KIT

92876A 9
Includes 15 in. (381 mm) extension coupler. Adjusts from 22 in. (560 mm) to 26‑1/2
in. (675 mm). See extension couplers for additional length.
Fits various Mercury/Mariner 70 thru 3.0 Litre outboards with two piece steering
arms.
STEERING ARM EXTENSION KIT
11606A 1
Starboard cable entry.
Fits Mercury/Mariner 6/8/9.9/15 hp. (2 cyl.) 2 cycle outboards (USA 0A197112 and
Newer, BEL 9461526 and Newer), 8 hp. 4‑Stroke outboards (232 cc) and 9.9 hp.
4‑Stroke outboards (0H000058‑0H016909).
STEERING ATTACHING KIT

17729A 1
Used with dual engine tie bar kits. Not designed for use with hydraulic or power
steering systems or as a primary steering attachment point.
Fits Mercury/Mariner 70/75/80 hp. when installing a single cable‑dual engine tie
bar kit and included standard in a dual cable‑dual engine tie bar kit.
CABLE SEAL KIT
19608A14
SEAL KIT Starboard cable entry.
Fits various Mercury/Mariner 25 thru 60 hp. and Force 40/50 hp. outboards. See
application chart for specific engine models.
STEERING ATTACHING KIT QUICKSILVER® RIGGING

19624A 1
Used in outboard applications.
Seals output end of tilt tube, helping to prevent corrosion of the RideGuide cable in
a thru tube steering arrangement. 19609A 6
Port cable entry.
Fits various Mercury/Mariner 25 thru 60 hp. and Force 40/50 hp. outboards. See
application chart for specific engine models.

Quicksilver Product Guide 247
