FOURSTROKE V6 AND V8 MODELS

TRIM ROD GUIDE REMOVAL TOOL ADAPTER FITTING

91- 44487T 1 91-822778A 2
Aids in the removal of the trim rod from the trim cylinders. Install in place of the manual release valve to measure the internal pressure of the
power trim pump in the up mode.
POWER TRIM TEST GAUGE KIT
ADAPTER FITTING

FOURSTROKE V6 AND V8 MODELS Test circuit pressures for various trim pumps. Install in place of the manual release valve to measure the internal pressure of the

91- 52915A 6
91-822778A 3
SPANNER WRENCH
power trim pump in the down mode.
POWER TRIM ADAPTER FITTING

91- 74951
Removes and installs trim cylinder end caps.
END CAP TOOL 91-822778004
Replaces power trim manual release valve when testing power trim circuits.
SPANNER NUT SOCKET

91-821709T
Trim Cylinder End Cap Tool
Allow easy removal of the trim cylinder end caps. Required if tilt limit spacers are
to be installed or if the trim in limit spacer is to be removed to allow additional trim 91-897957T
in range. Aids in the removal and installation of the upper mount spanner nut.
TRIM CYLINDER END CAP TOOL

91-8M0105203
Used to remove the end cap of the power trim cylinder.
