FOURSTROKE V6 AND V8 MODELS
PILOT WASHER DRIVESHAFT BEARING RETAINER WRENCH
91- 43506T
91- 36571T Removes and installs the threaded driveshft bearing retainer.
Used in pinion gear and pinion bearing installation. PULLER JAW ASSEMBLY
UNIVERSAL PULLER PLATE
91- 46086A 1 FOURSTROKE V6 AND V8 MODELS
91- 37241 Use with P/N 85716 puller bolt.
Removes bearings from gears and the driveshaft. Aids in the removal of the bearing carrier and bearing races.
PULLER PLATE PINION GEAR HEIGHT TOOL
91-8M0160428
Removes bearings from gears and the driveshaft.
For 4‑stroke V6 and V8 5.44 gearcases.
DRIVER ROD
91- 56048001
Measures pinion gear height.
DIAL INDICATOR TOOL
91- 37323
Aids in the removal and installation of various bearings and bearing races.
PULLER/DRIVER HEAD
91- 58222A 1
Measures distance, movement and runnout. Used for the drive system assembly
and engine setup.
91- 38628T
Used in pinion gear and pinion bearing installation.
Mercury Service Tool Guide 127
