VAZER STERNDRIVE

PINION NUT WRENCH BEARING ADAPTER TOOL VAZER STERNDRIVE

91-8M2005644 91- 18605A 2
Holds the pinion nut from removing the driveshaft and pinion gear. Installs the forwar gear bearing race on a standard gearcase. Presses the revese
gear bearing adapter into the gear housing on a counter‑rotation gearcase.
SHIMMING TOOL
OIL SEAL DRIVER

91-8M2005712 91- 31108T
Pinion gear shimming tool. Installs bearing carier oil seals.
Measures the pinion gear height for setting the pinion gear location.
CROSS BEARING REMOVAL AND INSTALLATION TOOL
BEARING PRELOAD TOOL KIT

91- 14311A04 91-866107A01
Simulates a load on the driveshaft for acurate pinion height and backlash Removes and installs the bearing caps on the cross bearings.
measurements.
BEARING REMOVAL AND INSTALLATION TOOL
U-JOINT RETAINER WRENCH

91- 31229A 7
91- 17256 Installs and removes the bearings in all gearcases.
Installs and torques the U‑Joint retainer nut.

Mercury Service Tool Guide 37
