Page 40 - Fluid Fitting 2018_extended

BSPT X BSPT 45 ELBOW BSPT X BSPP FIXED FEMALE
45 ELBOW

A B A

B
Part No Thread A Thread B
(BSPT) (BSPT)
Part No Thread A Thread B
C22220404 1/4” 1/4”
(BSPT) (BSPPF)
C22220606 3/8” 3/8”
C22200202 1/8” 1/8”
C22220808 1/2” 1/2”
C22200404 1/4” 1/4”
C22221212 3/4” 3/4”
C22200606 3/8” 3/8”
C22221616 1” 1”
C22200808 1/2” 1/2”
C22201212 3/4” 3/4”
C22201616 1” 1”
BSPT X BSPP 45 ELBOW C22202020 1.1/4” 1.1/4”
C22202424 1.1/2” 1.1/2”
C22203232 2” 2”

A B

Part No Thread A Thread B
(BSPT) (BSPP)
C22100202 1/8” 1/8”
C22100404 1/4” 1/4”
C22100606 3/8” 3/8”
C22100808 1/2” 1/2”
C22101212 3/4” 3/4”
C22101616 1” 1” BSPT FEMALE X BSPT FEMALE
C22102020 1.1/4” 1.1/4” 45 ELBOW
C22102424 1.1/2” 1.1/2”
C22103232 2” 2”
A B

BSPT X BSPP FEMALE SWIVEL 45

ELBOW Part No Thread A Thread B
(BSPTF) (BSPTF)
C24240404 1/4” 1/4”
B C24240606 3/8” 3/8”
C24240808 1/2” 1/2”
A C24241212 3/4” 3/4”
C24241616 1” 1”
Part No Thread A Thread B C24242020 1.1/4” 1.1/4”
(BSPT) (BSPPFS) C24242424 1.1/2” 1.1/2”
C22170404 1/4” 1/4” C24243232 2” 2”
C22170606 3/8” 3/8”
C22170808 1/2” 1/2”
C22171212 3/4” 3/4”
C22171616 1” 1”

PH: 0800 FITTINGS 24 HOURS. Page A36
