Page 46 - Fluid Fitting 2018_extended
P. 46
BSPT X BSPP FIXED FEMALE BSPP FIXED FEMALE X BSPP FIXED
90 ELBOW FEMALE 90 ELBOW
B
B
A
A
Part No Thread A Thread B
Part No Thread A Thread B (BSPPF) (BSPPF)
(BSPT) (BSPPF) B20200202 1/8” 1/8”
B22200202 1/8” 1/8” B20200404 1/4” 1/4”
B22200404 1/4” 1/4” B20200606 3/8” 3/8”
B22200606 3/8” 3/8” B20200808 1/2” 1/2”
B22200808 1/2” 1/2” B20201212 3/4” 3/4”
B22201212 3/4” 3/4” B20201616 1” 1”
B22201616 1” 1” B20202020 1.1/4” 1.1/4”
B22202020 1.1/4” 1.1/4” B20202424 1.1/2” 1.1/2”
B22202424 1.1/2” 1.1/2” B20203232 2” 2”
B22203232 2” 2”
BSPT FIXED FEMALE X BSPT FIXED BSPP ADJUSTABLE X BSPT 90
FEMALE 90 ELBOW ELBOW
B B
A
A
Part No Thread A Thread B
(BSPTF) (BSPTF)
Part No Thread A Thread B
B24240404 1/4” 1/4”
(BSPPAdj) (BSPT)
B24240606 3/8” 3/8”
B13220404 1/4” 1/4”
B24240808 1/2” 1/2”
B13220606 3/8” 3/8”
B24241212 3/4” 3/4”
B13220808 1/2” 1/2”
B24241616 1” 1”
B13221212 3/4” 3/4”
B24242020 1.1/4” 1.1/4”
B13221616 1” 1”
B24242424 1.1/2” 1.1/2”
B13222020 1.1/4” 1.1/4”
B24243232 2” 2”
