NPT FIXED FEMALE X NPT FIXED UNO ADJUSTABLE X JIC 90 ELBOW
FEMALE 90 ELBOW CONTINUED

B57501919 1.3/16” 1.3/16”
B B57501921 1.3/16” 1.5/16”
B57502117 1.5/16” 1.1/16”
B57502121 1.5/16” 1.5/16”
A B57502621 1.5/8” 1.5/16”

B57502626 1.5/8” 1.5/8”
Part No Thread A Thread B B57503026 1.7/8” 1.5/8”
(NPTF) (NPTF) B57503030 1.7/8” 1.7/8”
B36360202 1/8” 1/8”
B36360404 1/4” 1/4”
B36360606 3/8” 3/8”
B36360808 1/2” 1/2”
B36361212 3/4” 3/4”
B36361616 1” 1”
B36362020 1.1/4” 1.1/4”
B36362424 1.1/2” 1.1/2”
B36363232 2” 2”

UNO ADJUSTABLE X JIC 90 ELBOW UNO ADJUSTABLE X BSPT 90
ELBOW

B
B

A

A
Part No Thread A Thread B
(UNOAdj) (JIC)
B57500707 7/16” 7/16” Part No Thread A Thread B
B57500708 7/16” 1/2” (UNOAdj) (BSPT)
B57500709 7/16” 9/16” B57220704 7/16” 1/4”
B57500807 1/2” 7/16” B57220904 9/16” 1/4”
B57500808 1/2” 1/2” B57220906 9/16” 3/8”
B57500809 1/2” 9/16” B57221204 3/4” 1/4”
B57500907 9/16” 7/16” B57221206 3/4” 3/8”
B57500908 9/16” 1/2” B57221208 3/4” 1/2”
B57500909 9/16” 9/16” B57221406 7/8” 3/8”
B57500912 9/16” 3/4” B57221408 7/8” 1/2”
B57501209 3/4” 9/16” B57221412 7/8” 3/4”
B57501212 3/4” 3/4” B57221708 1.1/16” 1/2”
B57501214 3/4” 7/8” B57221712 1.1/16” 3/4”
B57501217 3/4” 1.1/16” B57222116 1.5/16” 1”
B57501409 7/8” 9/16”
B57501412 7/8” 3/4”
B57501414 7/8” 7/8”
B57501417 7/8” 1.1/16”
B57501712 1.1/16” 3/4”
B57501714 1.1/16” 7/8”
B57501717 1.1/16” 1.1/16”
B57501721 1.1/16” 1.5/16”
